Привет друзья и читатели сайта «Радиосхемы», продолжаем вместе с вами знакомиться с современными SMD радиодеталями. Сегодняшний обзор — по SMD транзисторам, которые вы наверно уже видели в современных различных электронных устройствах. Сначала большой справочник по планарным транзисторам, а затем как с ними работать.
Справочник по всем SMD транзисторам
| Коды на ‘0’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 0 | 2SC3603 | Nec | CX | SOT173 | Npn RF fT 7GHz | |
| 005 | SSTPAD5 | Sil | J | — | PAD-5 5pA leakage diode | |
| p01 | PDTA143ET | Phi | N | SOT23 | pnp dtr 4k7+4k7 | |
| t01 | PDTA143ET | Phi | N | SOT23 | pnp dtr 4k7+4k7 | |
| 01 | Gali-1 | MC | AZ | SOT89 | DC-8GHz MMIC amp 12dB gain | |
| 010 | SSTPAD10 | Sil | J | — | PAD-10 10pA leakage diode | |
| 011 | SO2369R | SGS | R | SOT23R | 2N2369 | |
| 02 | BST82 | Phi | M | — | n-ch mosfet 80V 175mA | |
| 02 | MRF5711L | Mot | X | SOT143 | npn RF MRF571 | |
| 02 | DTCC114T | Roh | N | — | 50V 100mA npn sw + 10k base res | |
| 02 | Gali-2 | MC | AZ | SOT89 | DC-8GHz MMIC amp 16dB gain | |
| p02 | PDTC143ET | Phi | N | SOT23 | npn 4k7+4k7 bias res | |
| t02 | PDTC143ET | Phi | N | SOT23 | npn 4k7+4k7 bias res | |
| 03 | Gali-3 | MC | AZ | SOT89 | DC-3GHz MMIC amp 22dB gain | |
| 03 | DTC143TE | Roh | N | EMT3 | npn dtr R1 4k7 50V 100mA | |
| 03 | DTC143TUA | Roh | N | SC70 | npn dtr R1 4k7 50V 100mA | |
| 03 | DTC143TKA | Roh | N | SC59 | npn dtr R1 4k7 50V 100mA | |
| 04 | DTC114TCA | Roh | N | SOT23 | npn dtr R1 10k 50V 100mA | |
| 04 | DTC114TE | Roh | N | EMT3 | npn dtr R1 10k 50V 100mA | |
| 04 | DTC114TUA | Roh | N | SC70 | npn dtr R1 10k 50V 100mA | |
| 04 | DTC114TKA | Roh | N | SC59 | npn dtr R1 10k 50V 100mA | |
| 04 | MRF5211L | Mot | X | SOT143 | pnp RF MRF521 | |
| 04 | Gali-4 | MC | AZ | SOT89 | DC-4GHz MMIC amp 17.5 dBm | |
| -04 | PMSS3904 | Phi | N | SOT323 | 2N3904 | |
| t04 | PMBS3904 | Phi | N | SOT23 | 2N3904 | |
| 05 | Gali-4 | MC | AZ | SOT89 | DC-4GHz MMIC amp 18 dBm o/p | |
| 05 | DTC124TE | Roh | N | EMT3 | npn dtr R1 22k 50V 100mA | |
| 05 | DTC124TUA | Roh | N | SC70 | npn dtr R1 22k 50V 100mA | |
| 05 | DTC124TKA | Roh | N | SC59 | npn dtr R1 22k 50V 100mA | |
| 05F | TSDF1205R | Tfk | WQ | — | fT12GHz npn 4V 5mA | |
| 06 | Gali-6 | MC | AZ | SOT89 | DC-4GHz MMIC amp 115 dBm o/p | |
| 06 | DTC144TE | Roh | N | EMT3 | npn dtr R1 47k 50V 100mA | |
| 06 | DTC144TUA | Roh | N | SC70 | npn dtr R1 47k 50V 100mA | |
| 06 | DTC144TKA | Roh | N | SC59 | npn dtr R1 47k 50V 100mA | |
| -06 | PMSS3906 | Phi | N | SOT323 | 2N3906 | |
| t06 | PMBS3906 | Phi | N | SOT23 | 2N3906 | |
| 020 | SSTPAD20 | Sil | J | — | PAD-20 20pA leakage diode | |
| 050 | SSTPAD50 | Sil | J | — | PAD-50 50pA leakage diode | |
| 081 | SO2369AR | SGS | R | SOT23R | 2N2369A | |
| 09 | DTC115TUA | Roh | N | SC70 | npn dtr R2 100k 50V 100mA | |
| 09 | DTC115TKA | Roh | N | SC59 | npn dtr R2 100k 50V 100mA | |
| 0A | MUN5111DW1 | Mot | DO | SOT363 | dual pnp dtr 10k+10k | |
| 0A | DTC125TUA | Roh | N | SC70 | npn dtr R2 100k 50V 100mA | |
| 0A | DTC125TKA | Roh | N | SC59 | npn dtr R2 100k 50V 100mA | |
| 0B | MUN5112DW1 | Mot | DO | SOT363 | dual pnp dtr 22k+22k | |
| 0C | MUN5113DW1 | Mot | DO | SOT363 | dual pnp dtr 47k+47k | |
| 0D | MUN5114DW1 | Mot | DO | SOT363 | dual pnp dtr 10k+47k | |
| 0E | MUN5115DW1 | Mot | DO | SOT363 | dual pnp dtr R1 10k | |
| 0F | MUN5116DW1 | Mot | DO | SOT363 | dual pnp dtr R1 4k7 | |
| 0G | MUN5130DW1 | Mot | DO | SOT363 | dual pnp dtr 1k0+1k0 | |
| 0H | MUN5131DW1 | Mot | DO | SOT363 | dual pnp dtr 2k2+2k2 | |
| 0J | MUN5132DW1 | Mot | DO | SOT363 | dual pnp dtr 4k7+4k7 | |
| 0K | MUN5133DW1 | Mot | DO | SOT363 | dual pnp dtr 4k7+47k | |
| 0L | MUN5134DW1 | Mot | DO | SOT363 | dual pnp dtr 22k+47k | |
| 0M | MUN5135DW1 | Mot | DO | SOT363 | dual pnp dtr 2k2+47k | |
| Коды на ‘1’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 1 | 2SC3587 | Nec | CX | — | npn RF fT10GHz | |
| 1 | BA277 | Phi | I | SOD523 | VHF Tuner band switch diode | |
| 1 (red) | BB669 | Sie | I | SOD323 | 56-2.7 pF varicap | |
| 10 | MRF9411L | Mot | X | SOT143 | npn Rf 8GHz MRF941 | |
| 10A | PZM10NB2A | Phi | A | SOT346 | dual ca 10V 0.3W zener | |
| 10V | PZM10NB | Phi | C | SOT346 | 10V 0.3W zener | |
| 10Y | BZV49-C10 | Phi | O | SOT89 | 10V 1W zener | |
| 11 | MRF9511L | Mot | X | SOT143 | npn RF 8GHz MRF951 | |
| 11 | MUN5311DW1 | Mot | DP | SOT363 | npn/pnp dtr 10k+10k | |
| 11 | PDTA114EU | Phi | N | SOT416 | pnp dtr | |
| p11 | PDTA114TT | Phi | N | SOT23 | pnp dtr | |
| t11 | PDTA114TT | Phi | N | SOT23 | pnp dtr | |
| 11A | PZM11NB2A | Phi | A | SOT346 | dual ca 11V 0.3W zener | |
| 11A | MMBD1501A | Nat | C | SOT23 | Si diode 200V 100mA | |
| 11V | PZM11NB | Phi | C | SOT346 | 11V 0.3W zener | |
| 11Y | BZV49-C11 | Phi | O | SOT89 | 11V 1W zener | |
| 12 | MUN5312DW1 | Mot | DP | SOT363 | npn/pnp dtr 22k+22k | |
| 12 | DTA123EUA | Rho | N | SC70 | pnp dtr 2k2+2k2 50V 100ma | |
| 12 | DTA123EKA | Rho | N | SC59 | pnp dtr 2k2+2k2 res 50V 100ma | |
| p12 | PDTC114TT | Phi | N | SOT23 | npn dtr | |
| t12 | PDTC114TT | Phi | N | SOT23 | npn dtr | |
| 12A | MMBD1502A | Nat | K | SOT23 | Si diode 200V 100mA | |
| 12A | PZM12NB2A | Phi | A | SOT346 | dual ca 12V 0.3W zener | |
| 12E | ZC2812E | Zet | D | SOT23 | dual series RF schottky15V 20mA | |
| 12V | PZM12NB | Phi | C | SOT346 | 12V 0.3W zener | |
| 12Y | BZV49-C12 | Phi | O | SOT89 | 12V 1W zener | |
| 13 | DTA143EUA | Rho | N | SC70 | pnp dtr 4k7+4k7 50V 100ma | |
| 13 | DTA143EKA | Rho | N | SC59 | pnp dtr 4k7+4k7 50V 100ma | |
| 13 | DTA143ECA | Rho | N | SOT23 | pnp dtr 4k7+4k7 50V 100ma | |
| 13t | BC846BPN | Phi | N | SOT363 | BC546B | |
| 13s | BAS125 | Sie | C | SOT23 | Schottky sw 24V 100mA | |
| 13s | BAS125W | Sie | C | SOT323 | Schottky sw 24V 100mA | |
| 13 | MA4CS103A | M/A | C | SOT23 | Schottky RF 20V 100mA | |
| 13 | MUN5313DW1 | Mot | DP | SOT363 | npn/pnp dtr 47k+47k | |
| 13A | MMBD1503A | Nat | D | SOT23 | dual Si diode 200V 100mA | |
| 13A | PZM13NB2A | Phi | A | SOT346 | dual ca 13V 0.3W zener | |
| 13E | ZC2813E | Zet | A | SOT23 | dual ca RF schottky15V 20mA | |
| 13V | PZM13NB | Phi | C | SOT346 | 13V 0.3W zener | |
| 13Y | BZV49-C13 | Phi | O | SOT89 | 13V 1W zener | |
| 14s | BAS125-04 | Sie | D | SOT23 | Dual series Schottky 25V 100mA | |
| 14s | BAS125-04W | Sie | D | SOT323 | Dual series Schottky 25V 100mA | |
| 14 | BAT114-099R | Sie | DQ | — | Quad Schottky crossover ring | |
| 14 | DTA114EUA | Roh | N | SC70 | pnp dtr 10k + 10k | |
| 14 | DTA114EKA | Roh | N | SC59 | pnp dtr 10k + 10k | |
| 14 | MUN5314DW1 | Mot | DP | SOT363 | npn/pnp dtr 10k R1 | |
| 14 | DTA114ECA | Roh | N | SOT23 | pnp dtr 10k + 10k | |
| 14A | MMBD1504A | Nat | B | — | dual cc Si diode 200V 100mA | |
| 15s | BAS125-05 | Sie | B | SOT23 | dual cc Schottky 25V 100mA | |
| 15s | BAS125-05W | Sie | B | SOT323 | dual cc Schottky 25V 100mA | |
| 15 | DTA124EUA | Roh | N | SC70 | pnp dtr 30V 50mA 22k+22k | |
| 15 | DTA124EKA | Roh | N | SC59 | pnp dtr 30V 50mA 22k+22k | |
| 15 | DTA124ECA | Roh | N | SOT23 | pnp dtr 30V 50mA 22k+22k | |
| 15 | MUN5315DW1 | Mot | DP | SOT363 | npn/pnp dtr 10k R1 | |
| 15 | MMBT3960 | Mot | N | — | 2N3960 | |
| 15A | MMBD1505A | Nat | A | — | dual ca Si diode 200V 100mA | |
| 15A | PZM15NB2A | Phi | A | SOT346 | dual ca 15V 0.3W zener | |
| 15V | PZM15NB | Phi | C | SOT346 | 15V 0.3W zener | |
| 15Y | BZV49-C15 | Phi | O | SOT89 | 15V 1W zener | |
| p16 | PDTC114ET | Phi | N | SOT23 | npn dtr | |
| t16 | PDTC114EU | Phi | N | SOT323 | npn dtr | |
| 16s | BAS125-06 | Sie | A | SOT23 | dual ca Schottky 25V 100mA | |
| 16s | BAS125-06W | Sie | A | SOT323 | dual ca Schottky 25V 100mA | |
| 16 | MUN5316DW1 | Mot | DP | SOT363 | npn/pnp dtr 4k7 R1 | |
| 16 | DTA144EUA | Roh | N | SC70 | pnp dtr 30V 50mA 47k+47k | |
| 16 | DTA144EKA | Roh | N | SC59 | pnp dtr 30V 50mA 47k+47k | |
| 16V | PZM16NB | Phi | C | SOT346 | 16V 0.3W zener | |
| 16Y | BZV49-C16 | Phi | O | SOT89 | 16V 1W zener | |
| 17s | BAS125-07 | Sie | S | SOT143 | dual Schottky 25V 100mA | |
| 17s | BAS125-07W | Sie | S | SOT343 | dual Schottky 25V 100mA | |
| p17 | PDTC124ET | Phi | N | SOT23 | npn dtr | |
| t17 | PDTC124EU | Phi | N | SOT323 | npn dtr | |
| 18 | BFP181T | Tfk | X | — | npn Rf fT 7.8GHz 10V 20mA | |
| 18 | PDTC143ZK | Phi | N | SOT346 | npn dtr 4k7+47k | |
| p18 | PDTC143ZT | Phi | N | SOT23 | npn dtr 4k7+47k | |
| t18 | PDTC143ZT | Phi | N | SOT23 | npn dtr 4k7+47k | |
| 18V | PZM18NB | Phi | C | SOT346 | 18V 0.3W zener | |
| 18Y | BZV49-C18 | Phi | O | SOT89 | 18V 1W zener | |
| 19 | PDTA143ZK | Phi | N | SOT346 | pnp dtr 4k7+47k | |
| 19 | DTA115EUA | Rho | N | SC70 | pnp dtr 100k+100k 50V 100ma | |
| 19 | DTA115EKA | Rho | N | SC59 | pnp dtr 100k+100k 50V 100ma | |
| p19 | PDTA143ZT | Phi | N | SOT23 | pnp dtr 4k7+47k | |
| t19 | PDTA143ZT | Phi | N | SOT23 | pnp dtr 4k7+47k | |
| 100 | SSTPAD100 | Sil | J | SOT23 | PAD-100 100pA leakage diode | |
| 101 | PZM10NB1 | Phi | C | SOT346 | 10V 0.3W zener | |
| 102 | PZM10NB2 | Phi | C | SOT346 | 10V 0.3W zener | |
| 103 | PZM10NB3 | Phi | C | SOT346 | 10V 0.3W zener | |
| 111 | PZM11NB1 | Phi | C | SOT346 | 11V 0.3W zener | |
| 111 | DTA113ZUA | Roh | N | SC70 | pnp dtr 1k+10k 50V 100mA | |
| 112 | PZM11NB2 | Phi | C | SOT346 | 11V 0.3W zener | |
| 113 | PZM11NB3 | Phi | C | SOT346 | 11V 0.3W zener | |
| 113 | DTA143ZUA | Roh | N | SC70 | pnp dtr 4k7+47k 50V 100mA | |
| 121 | PZM12NB1 | Phi | C | SOT346 | 12V 0.3W zener | |
| 121 | DTC113ZUA | Roh | N | SC70 | npn dtr 1k+10k 50V 100mA | |
| 122 | PZM12NB2 | Phi | C | SOT346 | 12V 0.3W zener | |
| 123 | PZM12NB3 | Phi | C | SOT346 | 12V 0.3W zener | |
| 123 | DTC143ZUA | Roh | N | SC70 | npn dtr 4k7+47k 50V 100mA | |
| 131 | PZM13NB1 | Phi | C | SOT346 | 13V 0.3W zener | |
| 132 | PZM13NB2 | Phi | C | SOT346 | 13V 0.3W zener | |
| 132 | DTA123JUA | Roh | N | SC70 | pnp dtr 2k2+47k 50V 100mA | |
| 133 | PZM13NB3 | Phi | C | SOT346 | 13V 0.3W zener | |
| 142 | DTA123JUA | Roh | N | SC70 | npn dtr 2k2+47k 50V 100mA | |
| 151 | PZM15NB1 | Phi | C | SOT346 | 15V 0.3W zener | |
| 152 | PZM15NB2 | Phi | C | SOT346 | 15V 0.3W zener | |
| 153 | PZM15NB3 | Phi | C | SOT346 | 15V 0.3W zener | |
| 156 | DTA144VUA | Roh | N | SC70 | pnp dtr 47k+10k 50V 100mA | |
| 161 | PZM16NB1 | Phi | C | SOT346 | 16V 0.3W zener | |
| 162 | PZM16NB2 | Phi | C | SOT346 | 16V 0.3W zener | |
| 163 | PZM16NB3 | Phi | C | SOT346 | 16V 0.3W zener | |
| 166 | DTC144VUA | Roh | N | SC70 | npn dtr 47k+10k 50V 100mA | |
| 179 | FMMT5179 | Zet | N | — | 2N5179 | |
| 181 | PZM18NB1 | Phi | C | SOT346 | 18V 0.3W zener | |
| 182 | PZM18NB2 | Phi | C | SOT346 | 18V 0.3W zener | |
| 183 | PZM18NB3 | Phi | C | SOT346 | 18V 0.3W zener | |
| 1A | BC846A | Phi | N | SOT23 | BC546A | |
| 1A | BC846AT | Phi | N | SOT416 | BC546A | |
| 1Ap | BC846A | Phi | N | SOT23 | BC546A | |
| 1At | BC846A | Phi | N | SOT23 | BC546A | |
| 1At | BC846AW | Phi | N | SOT323 | BC546A | |
| 1A- | BC846AW | Phi | N | SOT323 | BC546A | |
| 1A | FMMT3904 | Zet | N | SOT23 | 2N3904 | |
| 1A | MMBT3904 | Mot | N | SOT23 | 2N3904 | |
| 1A | IRLML2402 | IR | F | SOT23 | n-ch mosfet 20V 0.9A | |
| p1A | PMMT3904 | Phi | N | SOT23 | 2N3904 | |
| p1A | PXT3904 | Phi | N | SOT89 | 2N3904 | |
| t1A | PMMT3904 | Phi | N | SOT23 | 2N3904 | |
| t1A | PMST3904 | Phi | N | SOT323 | 2N3904 | |
| -1A | PMST3904 | Phi | N | SOT323 | 2N3904 | |
| 1AM | MMBT3904L | Mot | N | SOT23 | 2N3904 | |
| 1B | BC846B | Phi | N | SOT23 | BC546B | |
| 1B | BC846BT | Phi | N | SOT416 | BC546B | |
| 1Bp | BC846B | Phi | N | SOT23 | BC546B | |
| 1Bt | BC846B | Phi | N | SOT23 | BC546B | |
| 1Bt | BC846BW | Phi | N | SOT323 | BC546B | |
| 1B- | BC846BW | Phi | N | SOT323 | BC546B | |
| 1B | FMMT2222 | Zet | N | SOT23 | 2N2222 | |
| 1B | MMBT2222 | Mot | N | SOT23 | 2N2222 | |
| 1B | IRLML2803 | IR | F | SOT23 | n-ch mosfet 30V 0.9A | |
| p1B | PMBT2222 | Phi | N | SOT23 | 2N2222 | |
| t1B | PMBT2222 | Phi | N | SOT23 | 2N2222 | |
| t1B | PMST2222 | Phi | N | SOT233 | 2N2222 | |
| -1B | PMST2222 | Phi | N | SOT323 | 2N2222 | |
| 1Bs | BC817UPN | Sie | N | SC74 | — | |
| 1Cp | BAP50-05 | Phi | B | SOT23 | dual cc GP RF pin diode | |
| 1C | FMMT-A20 | Zet | N | SOT23 | MPSA20 | |
| 1C | MMBTA20L | Mot | N | SOT23 | MPS3904 | |
| 1C | IRLML6302 | IR | F | SOT23 | p-ch mosfet 20V 0.6A | |
| 1Cs | BC847S | Sie | — | SOT363 | BC457 | |
| 1Dp | BC846 | Phi | N | SOT23 | BC456 | |
| 1Dt | BC846 | Phi | N | SOT23 | BC456 | |
| 1Dt | BC846W | Phi | N | SOT323 | BC456 | |
| 1D- | BC846W | Phi | N | SOT323 | BC456 | |
| 1D | MMBTA42 | Mot | N | SOT23 | MPSA42 300V npn | |
| 1D | IRLML5103 | IR | F | SOT23 | p-ch mosfet 30V 0.6A | |
| p1D | PMBTA42 | Phi | N | SOT23 | MPSA42 300V npn | |
| p1D | PXTA42 | Phi | N | SOT89 | MPSA42 300V npn | |
| t1D | PMBTA42 | Phi | N | SOT23 | MPSA42 300V npn | |
| t1D | PMSTA42 | Phi | N | SOT323 | MPSA42 300V npn | |
| 1Ds | BC846U | Sie | N | SC74 | BC456 | |
| 1Ds | BC846U | Sie | — | SOT363 | BC456 | |
| 1DN | 2SC4083 | Roh | N | — | npn 11V 3.2GHz TV tuners | |
| 1DR | MSD1328R | Mot | N | SOT346 | npn gp 25V 500mA | |
| 1E | BC847A | Phi | N | SOT23 | BC547A | |
| 1E | BC847AT | Phi | N | SOT416 | BC547A | |
| 1Ep | BC847A | Phi | N | SOT23 | BC547A | |
| 1Et | BC847A | Phi | N | SOT23 | BC547A | |
| 1Et | BC847A | Phi | N | SOT323 | BC547A | |
| 1E- | BC847A | Phi | N | SOT323 | BC547A | |
| 1ER | BC847AR | Phi | R | SOT23R | BC547A | |
| 1E | FMMT-A43 | Zet | N | — | MPSA43 | |
| 1E | MMBTA43 | Mot | N | SOT23 | MPSA43 200V npn | |
| t1E | PMBTA43 | Mot | N | SOT23 | MPSA43 200V npn | |
| t1E | PMSTA43 | Mot | N | SOT323 | MPSA43 200V npn | |
| 1Es | BC847A | Sie | N | SOT23 | BC457 | |
| 1Es | BC847AW | Sie | N | SOT323 | BC457 | |
| 1EN | 2SC4084 | Roh | N | — | npn 20V 2.0GHz TV tuners | |
| 1F | BC847B | Phi | N | SOT23 | BC547B | |
| 1F | BC847BT | Phi | N | SOT416 | BC547B | |
| 1Fs | BC847B | Sie | N | SOT23 | BC547B | |
| 1Fs | BC847BT | Sie | N | SC75 | BC547B | |
| 1Fs | BC847BW | Sie | N | SOT323 | BC547B | |
| 1Fp | BC847B | Phi | N | SOT23 | BC547B | |
| 1Ft | BC847B | Phi | N | SOT23 | BC547B | |
| 1Ft | BC847BW | Phi | N | SOT323 | BC547B | |
| 1F- | BC847BW | Phi | N | SOT323 | BC547B | |
| 1FR | BC847BR | Phi | R | SOT23R | BC547B | |
| 1F | MMBT5550 | Mot | N | SOT23 | 2N5550 140V npn | |
| p1F | PMBT5550 | Phi | N | SOT23 | 2N5550 140V npn | |
| t1F | PMBT5550 | Phi | N | SOT23 | 2N5550 140V npn | |
| t1F | PMST5550 | Phi | N | SOT323 | 2N5550 140V npn | |
| 1FZ | FMBT5550 | Zet | N | SOT23 | 2N5550 140V npn | |
| 1G | BC847C | Phi | N | SOT23 | BC547C | |
| 1G | BC847CT | Phi | N | SOT416 | BC547C | |
| 1Gp | BC847C | Phi | N | SOT23 | BC547C | |
| 1Gt | BC847CW | Phi | N | SOT323 | BC547C | |
| 1G- | BC847CW | Phi | N | SOT323 | BC547C | |
| 1Gs | BC847C | Sie | N | SOT23 | BC547C | |
| 1Gs | BC847CW | Sie | N | SOT323 | BC547C | |
| 1GR | BC847CR | Phi | R | SOT23R | BC547C | |
| 1GT | SOA06 | SGS | N | SOT23 | MPSA06 | |
| 1G | FMMT-A06 | Zet | N | SOT23 | MPSA06 | |
| 1G | MMBTA06 | Mot | N | SOT23 | MPSA06 | |
| p1G | PMMTA06 | Phi | N | SOT23 | MPSA06 | |
| t1G | PMMTA06 | Phi | N | SOT23 | MPSA06 | |
| t1G | PMMTA06 | Phi | N | SOT323 | MPSA06 | |
| 1GM | MMBTA06 | Mot | N | SOT23 | MPSA06 | |
| 1Hp | BC847 | Phi | N | SOT23 | BC547 | |
| 1Ht | BC847 | Phi | N | SOT23 | BC547 | |
| 1Ht | BC847W | Phi | N | SOT323 | BC547 | |
| 1H- | BC847W | Phi | N | SOT323 | BC547 | |
| 1H | FMMT-A05 | Zet | N | — | MPSA05 | |
| 1H | MMBTA05 | Mot | N | SOT23 | MPSA05 | |
| t1H | MMBTA05 | Phi | N | SOT323 | MPSA05 | |
| 1HT | SOA05 | SGS | N | SOT23 | MPSA05 | |
| 1J | BC848A | Phi | N | SOT23 | BC548A | |
| 1Js | BC848A | Sie | N | SOT23 | BC548A | |
| 1Js | BC848AW | Sie | N | SOT323 | BC548A | |
| 1J | FMMT2369 | Zet | N | SOT23 | 2N2369 | |
| 1J | MMBT2369 | Mot | N | SOT23 | MPS2369 | |
| 1Js | BCV61A | Sie | VQ | SOT143 | npn current mirror hFe 180 | |
| 1Jp | BCV61A | Phi | VQ | SOT143 | npn current mirror hFe 180 | |
| p1J | PMBT2369 | Phi | N | SOT23 | 2N2369 | |
| t1J | PMBT2369 | Phi | N | SOT23 | 2N2369 | |
| t1J | PMBT2369 | Phi | N | SOT323 | 2N2369 | |
| 1JA | MMBT2369A | Mot | N | SOT23 | MPS2369A | |
| 1JR | BC848AR | Phi | R | SOT23R | BC548A | |
| 1JZ | BC848A | Zet | N | SOT23 | BC548A | |
| 1K | BC848B | ITT | N | SOT23 | BC548B | |
| 1Kp | BC848B | Phi | N | SOT23 | BC548B | |
| 1Ks | BC848B | Sie | N | SOT23 | BC548B | |
| 1Ks | BC848BW | Sie | N | SOT323 | BC548B | |
| 1K | MMBT6428 | Mot | N | SOT23 | MPSA18 50V | |
| p1K | PMBT6428 | Phi | N | SOT23 | MPSA18 50V | |
| t1K | PMBT6428 | Phi | N | SOT23 | MPSA18 50V | |
| t1K | PMBT6428 | Phi | N | SOT323 | MPSA18 50V | |
| 1K | FMMT4400 | Zet | N | SOT23 | 2N4400 | |
| 1Ks | BCV61B | Sie | VQ | SOT143B | npn current mirror hFe 290 | |
| 1Kp | BCV61B | Phi | VQ | SOT143B | npn current mirror hFe 290 | |
| 1KR | BC848BR | Phi | R | SOT23R | BC548B | |
| 1KM | MMBT6428L | Mot | N | SOT23 | MPSA18 50V | |
| 1KZ | FMMT4400 | Zet | N | SOT23 | 2N4400 | |
| 1L | BC848C | ITT | N | SOT23 | BC548C | |
| 1Lp | BC848C | Phi | N | SOT23 | BC548C | |
| 1Ls | BC848C | Sie | N | SOT23 | BC548C | |
| 1Ls | BC848CW | Sie | N | SOT323 | BC548C | |
| 1L | MMBT6429 | Mot | N | — | MPSA18 45V | |
| 1L | FMMT4401 | Zet | N | — | 2N4401 | |
| 1L | BCV61C | Sie | VQ | SOT143B | npn current mirror hFe 520 | |
| 1Lp | BCV61C | Phi | VQ | SOT143B | npn current mirror hFe 520 | |
| p1L | PMBT6429 | Phi | N | SOT23 | MPSA18 45V | |
| t1L | PMBT6429 | Phi | N | SOT23 | MPSA18 45V | |
| t1L | PMBT6429 | Phi | N | SOT323 | MPSA18 45V | |
| 1LR | BC848CR | Phi | R | SOT23R | BC548C | |
| 1Mp | BC848 | Phi | N | SOT23 | BC548 | |
| 1M | MMBTA13 | Mot | N | SOT23 | MPSA13 darlington | |
| 1Mp | BCV61 | Phi | VQ | SOT143B | npn current mirror | |
| 1M | FMMT-A13 | Zet | N | SOT23 | MPSA13 | |
| p1M | PXTA13 | Phi | N | SOT89 | MPSA13 darlington | |
| p1M | PMBTA13 | Phi | N | SOT23 | MPSA13 darlington | |
| t1M | PMBTA13 | Phi | N | SOT23 | MPSA13 darlington | |
| 1N | FMMT-A14 | Zet | N | SOT23 | MPSA14 | |
| 1N | MMBTA14 | Mot | N | SOT23 | MPSA14 darlington | |
| 1N5 | ZTX11N15DF | Zet | N | SOT23 | npn 15V 3A low saturation V | |
| p1N | PMBTA14 | Mot | N | SOT23 | MPSA14 darlington | |
| p1N | PXTA14 | Mot | N | SOT89 | MPSA14 darlington | |
| t1N | PMBTA14 | Mot | N | SOT23 | MPSA14 darlington | |
| 1P | FMMT2222A | Zet | N | — | 2N2222A | |
| 1P | MMBT2222A | Mot | N | SOT23 | 2N2222A | |
| 1P | BC847PN | Sie | DI | — | pnp/npn separate pair gp AF | |
| p1P | PMBT2222A | Phi | N | SOT23 | 2N2222A | |
| p1P | PXT2222A | Phi | N | SOT89 | 2N2222A | |
| t1P | PMBT2222A | Phi | N | SOT23 | 2N2222A | |
| t1P | PMST2222A | Phi | N | SOT323 | 2N2222A | |
| 1Q | MMBT5088 | Mot | N | SOT23 | MPSA18 Vce 30V | |
| p1Q | PMBT5088 | Phi | N | SOT23 | MPSA18 Vce 30V | |
| t1Q | PMBT5088 | Phi | N | SOT23 | MPSA18 Vce 30V | |
| t1Q | PMST5088 | Phi | N | SOT323 | MPSA18 Vce 30V | |
| 1R | MMBT5089 | Mot | N | SOT23 | MPSA18 Vce 25V | |
| t1R | PMST5089 | Phi | N | SOT323 | MPSA18 Vce 25V | |
| 1S | MMBT2369A | Nat | N | SOT23 | 2N2369A 500MHz sw npn | |
| 1S | MSC3130 | Mot | H | SOT346 | npn RF fT 1.4GHz 10V | |
| 1T | MMBT3960A | Mot | N | — | 2N3960A | |
| 1U | MMBT2484L | Mot | N | SOT23 | MPSA18 | |
| 1V | MMBT6427 | Mot | H | SOT23 | 2N6426/7 darlington npn | |
| 1Vp | BF820 | Phi | N | SOT23 | npn 300V 50mA BF420 | |
| 1Vt | BF820 | Phi | N | SOT23 | npn 300V 50mA BF420 | |
| 1Vt | BF820W | Phi | N | SOT323 | npn 300V 50mA BF420 | |
| 1V- | BF820W | Phi | N | SOT323 | npn 300V 50mA BF420 | |
| 1W | FMMT3903 | Zet | N | SOT23 | 2N3903 | |
| 1Wp | BF821 | Phi | N | SOT23 | pnp 300V 50mA BF421 | |
| 1Wt | BF821 | Phi | N | SOT23 | pnp 300V 50mA BF421 | |
| 1W t | BF822W | Phi | N | SOT323 | pnp 300V 50mA BF421 | |
| 1W — | BF822W | Phi | N | SOT323 | pnp 300V 50mA BF421 | |
| 1X | MMBT930L | Mot | N | SOT23 | MPS3904 | |
| 1Xp | BF822 | Phi | N | SOT23 | npn 250V 50mA BF422 | |
| 1Xt | BF822 | Phi | N | SOT23 | npn 250V 50mA BF422 | |
| 1Y | MMBT3903 | Mot | N | SOT23 | 2N3903 | |
| 1Yp | BF823 | Phi | N | SOT23 | pnp 250V 50mA BF423 | |
| 1Yt | BF823 | Phi | N | SOT23 | pnp 250V 50mA BF423 | |
| 1Z | BAS70-06 | Zet | A | SOT23 | dual RF CA schottky diode | |
| 1Z | MMBT6517 | Mot | N | SOT23 | 2N6517 npn Vce 350V | |
| Коды на ‘2’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 2 | BAT62-02W | Sie | I | SCD80 | BAT16 schottky diode | |
| 2 (blue) | BAR64-03W | Sie | I | SOD323 | pin diode | |
| 2 | 2SC3604 | Nec | CX | — | npn RF fT8GHz 12dB@2GHz | |
| 2 (white) | BB439 | Sie | I | SOD323 | 29-5 pF varicap | |
| 20 | MRF5811 | Mot | X | SOT143 | npn Rf fT 5GHz 0.2A | |
| -20 | PDTC114WU | Phi | N | SOT323 | npn dtr | |
| 20F | TSDF1220 | Tfk | X | SOT143 | fT 12GHz npn 6V 20mA | |
| 20V | PZM20NB | Phi | C | SOT346 | 20V 300mW zener | |
| 20Y | BZV49-C20 | Phi | O | SOT89 | 20V 1W zener | |
| 21 | Gali-21 | MC | AZ | SOT89 | DC-8GHz MMIC amp 14 dB gain | |
| 22 | MMBT4209 | Nat | N | SOT23 | pnp sw 850MHz 2N4209 | |
| 22 | DTC123EUA | Rho | N | SC70 | npn dtr 2k2+2k2 50V 100ma | |
| 22 | DTC123EKA | Rho | N | SC59 | npn dtr 2k2+2k2 50V 100ma | |
| 22V | PZM22NB | Phi | C | SOT346 | 22V 300mW zener | |
| 22Y | BZV49-C22 | Phi | O | SOT89 | 22V 1W zener | |
| 23 | MMBT3646 | Nat | N | SOT23 | npn sw 350MHz 2N3646 | |
| 23 | DTC143EUA | Roh | N | SC70 | pnp dtr 50V 100mA 4k7+ 4k7 | |
| 23 | DTC143EKA | Roh | N | SC59 | pnp dtr 50V 100mA 4k7+ 4k7 | |
| -23 | PDTA114TU | Phi | N | SOT323 | pnp dtr R1 10k | |
| t23 | PDTA114TU | Phi | N | SOT323 | pnp dtr R1 10k | |
| 24 | MMBD2101 | Nat | C | SOT23 | Si diode 100V 200mA | |
| 24 | DTC114ECA | Roh | N | SOT23 | npn dtr 50V 100mA 10k + 10k | |
| 24 | DTC114EUA | Roh | N | SC70 | npn dtr 50V 100mA 10k + 10k | |
| 24 | DTC114EKA | Roh | N | SC59 | npn dtr 50V 100mA 10k + 10k | |
| 24 | 2SC5006 | Nec | N | — | npn RF fT 4.5GHz @3V 7mA | |
| -24 | PDTC114TU | Phi | N | SOT323 | npn dtr R1 10k | |
| t24 | PDTC114TU | Phi | N | SOT323 | npn dtr R1 10k | |
| 24V | PZM24NB | Phi | C | SOT346 | 24V 300mW Zener | |
| 24Y | BZV49-C24 | Phi | O | SOT89 | 24V 1W zener | |
| 25 | MMBD2102 | Nat | K | SOT23 | Si diode 100V 200mA | |
| 25 | DTC124ECA | Roh | N | SOT23 | npn dtr 50V 100mA 22k + 22k | |
| 25 | DTC124EKA | Roh | N | SC59 | npn dtr 50V 100mA 22k + 22k | |
| 25 | DTC124EUA | Roh | N | SC70 | npn dtr 50V 100mA 22k + 22k | |
| 26 | MMBD2103 | Nat | D | SOT23 | dual MMBD1201 | |
| 26 | DTC144EKA | Roh | N | SC59 | npn dtr 50V 30mA 47k + 47k | |
| 26 | DTC144EUA | Roh | N | SC70 | npn dtr 50V 30mA 47k + 47k | |
| 27 | MMBD2104 | Nat | B | SOT23 | dual cc MMBD1201 | |
| 27V | PZM27NB | Phi | C | SOT346 | 27V 300mW Zener | |
| 27Y | BZV49-C27 | Phi | O | SOT89 | 27V 1W zener | |
| 28 | BFP280T | Tfk | W | — | npn RF fT 7GHz 8V 10mA | |
| 28 | MMBD2105 | Nat | A | SOT23 | dual ca MMBD1201 | |
| -28 | PDTA114WU | Phi | N | SOT323 | pnp dtr | |
| 29 | MMBD1401 | Nat | C | SOT23 | Si diode 200V 100mA | |
| 29 | DTC115EE | Roh | N | EMT3 | npn dtr 100k +100k 50V 20mA | |
| 29 | DTC115EUA | Roh | N | SC70 | npn dtr 100k +100k 50V 20mA | |
| 29 | DTC115EKA | Roh | N | SC59 | npn dtr 100k +100k 50V 20mA | |
| 200 | SSTPAD200 | Sil | J | — | PAD-200 200pA leakage diode | |
| 201 | PZM20NB1 | Phi | C | SOT346 | 20V 300mW Zener | |
| 202 | PZM20NB2 | Phi | C | SOT346 | 20V 300mW Zener | |
| 203 | PZM20NB3 | Phi | C | SOT346 | 20V 300mW Zener | |
| 221 | PZM22NB1 | Phi | C | SOT346 | 22V 300mW Zener | |
| 222 | PZM22NB2 | Phi | C | SOT346 | 22V 300mW Zener | |
| 223 | PZM22NB3 | Phi | C | SOT346 | 22V 300mW Zener | |
| 241 | PZM24NB | Phi | C | SOT346 | 24V 300mW Zener | |
| 242 | PZM24NB | Phi | C | SOT346 | 24V 300mW Zener | |
| 243 | PZM20NB | Phi | C | SOT346 | 24V 300mW Zener | |
| 271 | PZM2.7NB1 | Phi | C | SOT346 | 2.7V 300mW Zener | |
| 272 | PZM2.7NB2 | Phi | C | SOT346 | 2.7V 300mW Zener | |
| 2A | MMBT3906L | Mot | N | SOT23 | 2N3906 | |
| 2A | MMBT3906W | Mot | N | SOT323 | 2N3906 | |
| 2A | FMMT3906 | Zet | N | SOT23 | 2N3906 | |
| t2A | PMBT3906 | Phi | N | SOT23 | 2N3906 | |
| t2A | PMST3906 | Phi | N | SOT323 | 2N3906 | |
| p2A | PMBT3906 | Phi | N | SOT23 | 2N3906 | |
| p2A | PXT3906 | Phi | O | SOT89 | 2N3906 | |
| 2A4 | PZM2.4NB2A | Phi | A | SOT346 | dual 2.4V cc Zener | |
| 2A7 | PZM2.7NB2A | Phi | A | SOT346 | dual 2.7V cc Zener | |
| 2B | BC849B | ITT | N | SOT23 | BC549B | |
| 2Bs | BC849B | Sie | N | SOT23 | BC549B | |
| 2Bs | BC849BW | Sie | N | SOT323 | BC549B | |
| 2Bp | BC849B | Phi | N | SOT23 | BC549B | |
| 2Bt | BC849BW | Phi | N | SOT323 | BC549B | |
| 2B- | BC849BW | Phi | N | SOT323 | BC549B | |
| 2B | FMMT2907 | Zet | N | SOT23 | 2N2907 | |
| 2B | MMBT2907 | Mot | N | SOT23 | MPS2907 | |
| p2B | PMBT2907 | Phi | N | SOT23 | 2N2907 | |
| t2B | PMBT2907 | Phi | N | SOT23 | 2N2907 | |
| 2BR | BC849BR | Phi | R | SOT23R | BC549B | |
| 2BZ | FMMT2907 | Zet | N | SOT23 | 2N2907 | |
| 2C | BC849C | ITT | N | SOT23 | BC549C | |
| 2Cs | BC849C | Sie | N | SOT23 | BC549C | |
| 2Cs | BC849CW | Sie | N | SOT323 | BC549C | |
| 2Cp | BC849C | Phi | N | SOT23 | BC549C | |
| 2Ct | BC849C | Phi | N | SOT23 | BC549C | |
| 2Ct | BC849CW | Phi | N | SOT323 | BC549C | |
| 2C- | BC849CW | Phi | N | SOT323 | BC549C | |
| 2C | MMBTA70 | Mot | N | SOT23 | MPSA70 | |
| 2CR | BC849CR | Phi | R | SOT23R | BC549C | |
| 2CZ | FMMTA70 | Zet | N | SOT23 | MPSA70 | |
| 2D | MMBTA92 | Mot | N | SOT23 | MPSA92 pnp Vce 300V | |
| p2D | PMBTA92 | Phi | N | SOT23 | MPSA92 pnp Vce 300V | |
| p2D | PXTA92 | Phi | O | SOT89 | MPSA92 pnp Vce 300V | |
| t2D | PMBTA92 | Phi | N | SOT23 | MPSA92 pnp Vce 300V | |
| t2D | PMSTA92 | Phi | N | SOT323 | MPSA92 pnp Vce 300V | |
| 2E | MMBTA93 | Mot | N | SOT23 | MPSA93 pnp Vce 200V | |
| 2E | FMMT-A93 | Zet | N | SOT23 | MPSA93 | |
| t2E | PMBTA93 | Phi | N | SOT23 | MPSA93 pnp Vce 200V | |
| t2E | PMSTA93 | Phi | N | SOT323 | MPSA93 pnp Vce 200V | |
| 2F | BC850B | ITT | N | SOT23 | BC550B | |
| 2Fs | BC850B | Sie | N | SOT23 | BC550B | |
| 2Fs | BC850BW | Sie | N | SOT323 | BC550B | |
| 2Fp | BC850B | Phi | N | SOT23 | BC550B | |
| 2Ft | BC850B | Phi | N | SOT23 | BC550B | |
| 2Ft | BC850BW | Phi | N | SOT323 | BC550B | |
| 2F- | BC850BW | Phi | N | SOT323 | BC550B | |
| 2F | FMMT2907A | Zet | N | SOT23 | 2N2907A | |
| 2F | MMBT2907A | Mot | N | SOT23 | MPS2907A | |
| 2F | MMBT2907AW | Mot | N | SOT323 | MPS2907A | |
| p2F | PMBT2907A | Phi | N | SOT23 | 2N2907A | |
| p2F | PXT2907A | Phi | O | SOT89 | 2N2907A | |
| t2F | PMBT2907A | Phi | N | SOT23 | 2N2907A | |
| t2F | PMBT2907A | Phi | N | SOT323 | 2N2907A | |
| 2FR | BC850BR | Phi | R | SOT23R | BC550B | |
| 2G | BC850C | ITT | N | SOT23 | BC550C | |
| 2Gs | BC850C | Sie | N | SOT23 | BC550C | |
| 2Gp | BC850C | Phi | N | SOT23 | BC550C | |
| 2Gt | BC850C | Phi | N | SOT323 | BC550C | |
| 2Gt | BC850CW | Phi | N | SOT323 | BC550C | |
| 2G- | BC850CW | Phi | N | SOT323 | BC550C | |
| 2G | FMMT-A56 | Zet | N | SOT23 | MPSA56 | |
| 2G | MMBTA56 | Mot | N | SOT23 | MPSA56 | |
| p2G | PMBTA56 | Phi | N | SOT23 | MPSA56 | |
| t2G | PMBTA56 | Phi | N | SOT23 | MPSA56 | |
| t2G | PMSTA56 | Phi | N | SOT323 | MPSA56 | |
| 2GM | MMBTA56 | Mot | N | SOT23 | MPSA56 | |
| 2GR | BC850CR | Phi | R | SOT23R | BC550C | |
| 2GT | SOA56 | SGS | N | SOT23 | MPSA56 | |
| 2H | FMMT-A55 | Zet | N | SOT23 | MPSA55 | |
| 2HT | SOA55 | SGS | N | SOT23 | MPSA55 | |
| 2H | MMBTA55 | Mot | N | SOT23 | MPSA55 | |
| t2H | PMBTA55 | Phi | N | SOT23 | MPSA55 | |
| t2H | PMSTA55 | Phi | N | SOT323 | MPSA55 | |
| 2J | MMBT3640 | Mot | N | SOT23 | MPS3640 pnp sw | |
| 2K | FMMT4402 | Zet | N | SOT23 | 2N4402 | |
| 2K | MMBT8598 | Mot | N | — | 2N4125 pnp 60V | |
| 2L | MMBT5401 | Mot | N | SOT23 | 2N5401 pnp 150V | |
| 2L | FMMT4403 | Zet | N | SOT23 | 2N4403 | |
| p2L | PMBT5401 | Phi | N | SOT23 | 2N5401 pnp 150V | |
| t2L | PMBT5401 | Phi | N | SOT23 | 2N5401 pnp 150V | |
| t2L | PMST5401 | Phi | N | SOT323 | 2N5401 pnp 150V | |
| 2M | FMMT5087 | Zet | N | SOT23 | 2N5087 | |
| 2M | MMBT404 | Mot | N | SOT23 | pnp-chopper 24V 150mA | |
| 2N | MMBT404A | Mot | N | SOT23 | pnp-chopper 35V 150mA | |
| 2N0 | ZXT11N20DF | Zet | N | SOT23 | npn 20V 2.5A low sat switch | |
| 2P | FMMT2222R | Zet | R | SOT23R | 2N2222 | |
| 2P | MMBT5086 | Mot | N | SOT23 | 2N5086 | |
| 2Q | MMBT5087 | Mot | N | SOT23 | 2N5087 | |
| 2R | HSMS-8102 | HP | Z | SOT23 | 10-14GHz schottky mixer pair | |
| 2T | SO4403 | SGS | N | SOT23 | 2N4403 | |
| 2T | MMBT4403 | Mot | N | SOT23 | 2N4403 | |
| p2T | PMBT4403 | Phi | N | SOT23 | 2N4403 | |
| p2T | PXT4403 | Phi | O | SOT89 | 2N4403 | |
| t2T | PMBT4403 | Phi | N | SOT23 | 2N4403 | |
| t2T | PMST4403 | Phi | N | SOT323 | 2N4403 | |
| 2T | HT2 | Zet | N | SOT23 | pnp 80V 100mA | |
| 2U | MMBTA63 | Mot | N | SOT23 | MPSA63 darlington | |
| t2U | PMBTA63 | Phi | N | SOT23 | MPSA63 darlington | |
| 2V | MMBTA64 | Mot | N | SOT23 | MPSA64 darlington | |
| p2V | PXTA64 | Phi | O | SOT89 | MPSA64 darlington | |
| t2V | PMBTA64 | Phi | H | SOT23 | MPSA64 darlington | |
| 2V4 | PZM2.4NB | Phi | C | SOT346 | 2.4V 300mW Zener | |
| 2V7 | PZM2.7NB | Phi | C | SOT346 | 2.7V 300mW Zener | |
| 2W | FMMT3905 | Zet | N | SOT23 | 2N3905 | |
| 2W | MMBT8599 | Mot | N | — | 2N4125 Vce 80V pnp | |
| 2X | SO4401 | SGS | N | SOT23 | 2N4401 | |
| 2X | MMBT4401 | Mot | N | SOT23 | 2N4401 | |
| p2X | PMBT4401 | Phi | N | SOT23 | 2N4401 | |
| p2X | PxT4401 | Phi | O | SOT89 | 2N4401 | |
| t2X | PMBT4401 | Phi | N | SOT23 | 2N4401 | |
| t2X | PMST4401 | Phi | N | SOT323 | 2N4401 | |
| 2Y4 | BZV49-C2V4 | Phi | O | SOT89 | 2.4V 1W zener | |
| 2Y7 | BZV49-C2V7 | Phi | O | SOT89 | 2.7V 1W zener | |
| 2Z | MMBT6520 | Mot | N | SOT23 | 2N6520 pnp Vce 350V | |
| 2Z | BAS70-04 | Zet | D | SOT23 | dual series RF schottky 70V 15mA | |
| 2Z5 | BAS70-05 | Zet | B | SOT23 | dual cc RF Schottky 70V 15mA | |
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data |
| 3 | BAT60A | Sie | I | SOD323 | 10V 3A sw schottky |
| 3 | BAT62-02W | Sie | I | SCD80 | — |
| 30 | MUN5330DW1 | Mot | DP | SOT363 | npn/pnp dtr 1k0+1k0 |
| 30V | PZM30NB1 | Phi | C | SOT346 | 30V 300mW zener |
| 30Y | BZV49-C30 | Phi | O | SOT89 | 30V 1W zener |
| 301 | FDV301N | Fch | M | SOT23 | n-ch ‘digital’ fet 25V 0.22A |
| 302 | FDV302P | Fch | M | SOT23 | p-ch ‘digital’ fet 25V 0.13A |
| 303 | FDV303N | Fch | M | SOT23 | n-ch ‘digital’ fet 25V 0.68A |
| 304 | FDV304P | Fch | M | SOT23 | p-ch ‘digital’ fet 25V 0.46A |
| 31 | MUN5331DW1 | Mot | DP | SOT363 | npn/pnp dtr 2k2+2k2 |
| 31 | MMBD1402 | Nat | K | SOT23 | Si diode 200V 100mA |
| p31 | PDTA143XT | Phi | N | SOT23 | pnp dtr 4k7+10k |
| t31 | PDTA143XT | Phi | N | SOT23 | pnp dtr4k7+10k |
| 32 | MUN5332DW1 | Mot | DP | SOT363 | npn/pnp dtr 4k7+4k7 |
| 32 | MMBD1403 | Nat | D | SOT23 | dual Si diode 200V 100mA |
| 32 | BAT32 | Sie | CS | — | 18GHz zero-bias schottky |
| p32 | PDTC143XT | Phi | N | SOT23 | pnp dtr 4k7+10k |
| t32 | PDTC143XT | Phi | N | SOT23 | pnp dtr 4k7+10ks |
| 33 | MUN5333DW1 | Mot | DP | SOT363 | npn/pnp dtr 4k7+47k |
| 33 | DTA143XE | Roh | N | EMT3 | pnp dtr 4k7+10k 50V 100mA |
| 33 | DTA143XUA | Roh | N | SC70 | pnp sw 4k7+10k bias res 50V 100mA |
| 33 | DTA143XKA | Roh | N | SC59 | pnp sw 4k7+10k bias res 50V 100mA |
| 33 | MMBD1404 | Nat | B | SOT23 | dual cc Si diode 200V 100mA |
| 33 | Gali-33 | MC | AZ | SOT89 | DC-4GHz MMIC amp 19dB gain |
| 33V | PZM33NB1 | Phi | C | SOT346 | 33 300mW zener |
| 33Y | BZV49-C33 | Phi | O | SOT89 | 33V 1W zener |
| 34 | MUN5334DW1 | Mot | DP | SOT363 | npn/pnp dtr 22k+47k |
| 34 | MMBD1405 | Nat | A | SOT23 | dual ca Si diode 200V 100mA |
| 331 | NDS331N | Fch | M | SOT23 | n-ch mosfet 1.3A 20V |
| 331 | PZM3.3NB1 | Phi | C | SOT346 | 3.3V 300mW zener |
| 332 | PZM3.3NB2 | Phi | C | SOT346 | 3.3V 300mW zener |
| 332 | NDS332N | Fch | M | SOT23 | p-ch mosfet 0.4A, 1A pk, 20V |
| 335 | NDS335N | Fch | M | SOT23 | n-ch mosfet 70 mA, 1.7A pk, 20V |
| 336 | NDS336N | Fch | M | SOT23 | p-ch mosfet 0.27A, 1.2A pk, 20V |
| 337 | NDS337N | Fch | M | SOT23 | n-ch mosfet 50 mA, 2.5A pk 20V |
| 338 | NDS338N | Fch | M | SOT23 | p-ch mosfet 0.13A, 1.6Apk 20V |
| 34 | 2SC5007 | Nec | N | — | npn RF fT 7GHz @3V 7mA |
| 340 | FDV340P | Fch | M | SOT23 | p-ch mosfet 20V 70 mA |
| 35 | MUN5335DW1 | Mot | DP | SOT363 | npn/pnp dtr 2k2+47k |
| 35 | DTA124XE | Roh | N | EMT3 | pnp dtr 22k+47k 50V 50mA |
| 35 | DTA124XUA | Roh | N | SC70 | pnp dtr 22k+47k 50V 50mA |
| 35 | DTA124XKA | Roh | N | SC59 | pnp dtr 22k+47k 50V 50mA |
| 351 | NDS351N | Fch | M | SOT23 | n-ch mosfet 1.1A 30V |
| 352 | NDS352N | Fch | M | SOT23 | p-ch mosfet 0.5A 20V |
| 355 | NDS355N | Fch | M | SOT23 | n-ch mosfet 0.1A, 1.6A pk 30V |
| 356 | NDS356N | Fch | M | SOT23 | p-ch mosfet 0.3A, 1.1A pk 20V |
| 357 | NDS357N | Fch | M | SOT23 | n-ch mosfet 2.5Apk 30V |
| 358 | NDS358N | Fch | M | SOT23 | p-ch mosfet 0.2A, 1.6A pk 30V |
| 358 | FDN358N | Fch | M | SOT23 | p-ch mosfet 0.2A 1.6A pk 30V |
| 360 | FDN360P | Fch | M | SOT23 | p-ch mosfet 80mA, 2a PK, 30V |
| 361 | PZM3.6NB1 | Phi | C | SOT346 | 3.6V 300mW Zener |
| 362 | PZM3.3NB2 | Phi | C | SOT346 | 3.6V 300mW Zener |
| 36V | PZM36NB1 | Phi | C | SOT346 | 36V 300mW Zener |
| 36Y | BZV49-C36 | Phi | O | SOT89 | 36V 1W zener |
| 391 | PZM3.9NB1 | Phi | C | SOT346 | 3.9V 300mW Zener |
| 392 | PZM3.9NB2 | Phi | C | SOT346 | 3.9V 300mW Zener |
| 39V | PZM39NB1 | Phi | C | SOT346 | 39V 300mW Zener |
| 39Y | BZV49-C39 | Phi | O | SOT89 | 39V 1W zener |
| 3A | BC856A | ITT | N | SOT23 | BC556A |
| 3A | BC856AT | Phi | N | SOT416 | BC556A |
| 3Ap | BC856A | Phi | N | SOT23 | BC556A |
| 3At | BC856A | Phi | N | SOT23 | BC556A |
| 3As | BC856A | Sie | N | SOT23 | BC556A |
| 3At | BC856AW | Phi | N | SOT323 | BC556A |
| 3A- | BC856AW | Phi | N | SOT323 | BC556A |
| 3A | MMBTH24 | Mot | N | SOT23 | VHF mixer npn fT 600MHz |
| 3A0 | PZM3.0NB2A | Phi | C | SOT346 | dual 3.0V Zener |
| 3A3 | PZM3.3NB2A | Phi | C | SOT346 | dual 3.3V Zener |
| 3A6 | PZM3.6NB2A | Phi | C | SOT346 | dual 3.6V Zener |
| 3A9 | PZM3.9NB2A | Phi | C | SOT346 | dual 3.9V Zener |
| 3AR | BC856AR | Phi | R | SOT23R | BC556A |
| 3B | BC856B | ITT | N | SOT23 | BC556B |
| 3B | BC856BT | Phi | N | SOT416 | BC556B |
| 3Bp | BC856B | Phi | N | SOT23 | BC556B |
| 3Bs | BC856B | Sie | N | SOT23 | BC556B |
| 3Bt | BC856B | Phi | N | SOT23 | BC556B |
| 3Bt | BC856BW | Phi | N | SOT323 | BC556B |
| 3B- | BC856BW | Phi | N | SOT323 | BC556B |
| 3B | FMMT918 | Zet | N | SOT23 | 2N918 |
| 3B | MMBT918 | Mot | N | SOT23 | 2N918 |
| 3BR | BC856BR | Phi | R | SOT23 | BC556B |
| 3C | FMMTA20R | Zet | R | SOT23R | MPSA20 |
| 3C | BC857 | Sie | DO | — | pnp separate pair gp AF |
| 3D | BC856 | Phi | N | SOT23 | BC556 hfe 75 min |
| 3Dp | BC856 | Phi | N | SOT23 | BC556 hfe 75 min |
| 3Dt | BC856 | Phi | N | SOT23 | BC556 hfe 75 min |
| 3Dt | BC856W | Phi | N | SOT323 | BC556 hfe 75 min |
| 3D- | BC856W | Phi | N | SOT323 | BC556 hfe 75 min |
| 3D | MMBTH81L | Mot | N | SOT23 | UHF pnp fT 600MHz |
| 3D | BC856S | Sie | DO | — | pnp separate pair gp AF |
| 3E | BC857A | Phi | N | SOT23 | BC557A |
| 3E | BC857AT | Phi | N | SOT416 | BC557A |
| 3Ep | BC857A | Phi | N | SOT23 | BC557A |
| 3Et | BC857A | Phi | N | SOT23 | BC557A |
| 3Et | BC857A | Phi | N | SOT323 | BC557A |
| 3E- | BC857A | Phi | N | SOT323 | BC557A |
| 3E | MMBTH10 | Mot | N | SOT23 | MPSH10 fT 650MHz |
| 3E | FMMT-A42 | Zet | N | SOT23 | MPSA42 |
| 3EM | MMBTH10L | Mot | N | SOT23 | VHF amp 650MHz fT |
| 3ER | BC857AR | Phi | R | SOT23R | BC557A |
| 3EZ | FMMTH10 | Zet | N | SOT23 | npn fT 650MHz |
| 3F | BC857B | Phi | N | SOT23 | BC557B |
| 3F | BC857BT | Phi | N | SOT416 | BC557B |
| 3Fp | BC857B | Phi | N | SOT23 | BC557B |
| 3Fs | BC857B | Sie | N | SOT23 | BC557B |
| 3Ft | BC857B | Phi | N | SOT23 | BC557B |
| 3Ft | BC857BW | Phi | N | SOT323 | BC557B |
| 3Ft | BC857BS | Phi | N | SOT363 | BC557B |
| 3F- | BC857BW | Phi | N | SOT323 | BC557B |
| 3FR | BC857BR | Phi | R | SOT23R | BC557B |
| 3G | BC857C | Phi | N | SOT23 | BC557C |
| 3Gp | BC857C | Phi | N | SOT23 | BC557C |
| 3G | BC857C | Phi | N | SOT23 | BC557C |
| 3Gs | BC857C | Sie | N | SOT23 | BC557C |
| 3Gt | BC857C | Phi | N | SOT23 | BC557C |
| 3Gt | BC857CW | Phi | N | SOT323 | BC557C |
| 3G- | BC857CW | Phi | N | SOT323 | BC557C |
| 3G | MMBTH11 | NS | N | SOT23 | — |
| 3G | MGSF3454X | Mot | DK | TSOP6 | n-ch enh tmosfet 1.75A |
| 3GR | BC857CR | Phi | R | SOT23R | BC557CR |
| 3Hp | BC857C | Phi | N | SOT23 | BC557 |
| 3Ht | BC857C | Phi | N | SOT23 | BC557 |
| 3Ht | BC857CW | Phi | N | SOT323 | BC557 |
| 3H | MMBTH30 | NS | N | SOT23 | — |
| 3H- | BC857CW | Phi | N | SOT323 | BC557 |
| 3J | MMBTH69 | Mot | N | SOT23 | pnp UHF fT 2GHz |
| 3J | BC858A | Phi | N | SOT23 | BC558A |
| 3Js | BC858A | Sie | N | SOT23 | BC558A |
| 3JR | BC858AR | Phi | R | SOT23R | BC558A |
| 3Js | BCV62A | Sie | VQ | SOT143 | pnp current mirror hFe 180 |
| 3Jp | BCV62A | Phi | VQ | SOT143 | pnp current mirror hFe 180 |
| 3K | BC858B | Phi | N | SOT23 | BC558B |
| 3Ks | BCV62B | Sie | VQ | SOT143 | npn current mirror hFe 290 |
| 3Kp | BCV62B | Phi | VQ | SOT143 | npn current mirror hFe 290 |
| 3KR | BC858BR | Phi | R | SOT23R | BC558B |
| 3L | BC858C | Phi | N | SOT23 | BC558C |
| 3LR | BC858CR | Phi | R | SOT23R | BC558C |
| 3Ls | BCV62C | Sie | VQ | SOT143 | pnp current mirror hFe 520 |
| 3Lp | BCV62C | Phi | VQ | SOT143 | pnp current mirror hFe 520 |
| 3M | BC858 | Phi | N | SOT23 | BC558 |
| 3M | FMMT5087R | Zet | R | SOT23R | 2N5087 BC322 |
| 3Ms | BCV62 | Sie | VQ | SOT143 | pnp current mirror |
| 3Mp | BCV62 | Phi | VQ | SOT143 | pnp current mirror |
| 3N | MMBT4402 | Nat | N | SOT23 | 2N4402 pnp |
| 3P | FMT2222AR | Zet | R | SOT23R | 2N2222A |
| 3R | MMBT5571 | Nat | N | SOT23 | pnp sw 850MHz |
| 3S | MMBT5551 | Nat | N | SOT23 | npn 160V |
| 3T | HT3 | Zet | N | SOT23 | npn 80V 100mA |
| 3V0 | PZM3.0NB | Phi | C | SOT346 | 3.0V 300mW Zener |
| 3V3 | PZM3.3NB | Phi | C | SOT346 | 3.3V 300mW Zener |
| 3V6 | PZM3.6NB | Phi | C | SOT346 | 3.6V 300mW Zener |
| 3V9 | PZM3.9NB | Phi | C | SOT346 | 3.9V 300mW Zener |
| 3W | FMMT-A12 | Zet | N | — | MPSA12 |
| 3Y3 | BZV49-C3V3 | Phi | O | SOT89 | 3.3V 1W zener |
| 3Y6 | BZV49-C3V6 | Phi | O | SOT89 | 3.6V 1W zener |
| 3Y9 | BZV49-C3V9 | Phi | O | SOT89 | 3.9V 1W zener |
| Коды на ‘4’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 4 (white) | BAS140W | Sie | I | SOD323 | 40V 120mA sw schottky | |
| 4 (yellow) | BB644 | Sie | I | SOD323 | Varicap 42-2.5pF | |
| 4 (red) | BB57-03W | Sie | I | SOD323 | Varicap | |
| 4 | BB664 | Sie | I | SCD80 | Varicap 42-2.5pF | |
| 41 | BAT14-115S | Sie | CS | SOT173 | 40GHz schottky diode | |
| 41 | BAT14-115R | Sie | CZ | SOT173 | 40GHz schottky ring quad | |
| 41A | FMMT491A | Zet | N | SOT23 | npn 40v 1A max | |
| 41D | BAT14-115D | Sie | CY | SOT173 | 40GHz schottky dual | |
| 42 | BAT14-025S | Sie | CS | SOT173 | 4GHz schottky diode | |
| 42 | BAT14-025R | Sie | CZ | SOT173 | 4GHz schottky ring quad | |
| 42D | BAT14-025D | Sie | CY | SOT173 | 4GHz schottky dual | |
| 43 | BAS40 | Sie | C | SOT23 | schottky diode 40V 100mA | |
| 43 | DTA143EE | Mot | N | SOT416 | pnp dtr 4k7 + 4k7 | |
| 43 | DTC143XE | Roh | N | EMT3 | npn dtr 4k7+10k 50V 100mA | |
| 43 | DTC143XUA | Roh | N | SC70 | npn dtr 4k7+10k 50V 100mA | |
| 43 | DTC143XKA | Roh | N | SC59 | npn dtr 4k7+10k 50V 100mA | |
| 43V | PZM43NB | Phi | C | SOT346 | 43V 0.3W zener | |
| 43Y | BZV49-C43 | Phi | O | SOT89 | 43V 1W zener | |
| 44 | BAS40-04 | Sie | D | SOT23 | dual series BAS40 | |
| 44 | BAS40-04W | Sie | D | SOT323 | dual series BAS40 | |
| 44 | 2SC5009 | Nec | N | — | npn RF fT 12GHz @3V 5mA | |
| 45 | BAS40-05 | Sie | A | SOT23 | dual ca BAS40 | |
| 45 | BAS40-05W | Sie | A | SOT323 | dual ca BAS40 | |
| 45 | BAT14-055S | Sie | CS | SOT173 | 8GHz schottky diode | |
| 45 | BAT14-055R | Sie | CZ | SOT173 | 8GHz schottky ring quad | |
| 45 | DTC124XE | Roh | N | EMT3 | npn dtr 22k+47k 50V 50mA | |
| 45 | DTC124XUA | Roh | N | SC70 | npn dtr 22k+47k 50V 50mA | |
| 45 | DTC124XKA | Roh | N | SC59 | npn dtr 22k+47k 50V 50mA | |
| 45D | BAT14-055D | Sie | CY | SOT173 | 8GHz schottky dual | |
| 46 | BAS40-06 | Sie | B | SOT23 | dual cc BAS40 | |
| 46 | BAS40-06W | Sie | B | SOT323 | dual cc BAS40 | |
| 46 | MBT3946DW | Mot | DP | — | 2N3904/2N3906 pair | |
| 47 | BAS40-07 | Sie | S | SOT143 | dual BAS40 | |
| 47 | BAS40-07W | Sie | S | SOT343 | dual BAS40 | |
| 47V | PZM47NB | Phi | C | SOT346 | 47V 0.3W zener | |
| 47Y | BZV49-C47 | Phi | O | SOT89 | 47V 1W zener | |
| 49 | BAT14-095S | Sie | CS | SOT173 | 18GHz shottky diode | |
| 49 | BAT14-095R | Sie | CZ | SOT173 | 18GHz schottky ring quad | |
| 49D | BAT14-095D | Sie | CY | SOT173 | 18GHz schottky dual | |
| 413 | FMMT413 | Zet | N | SOT23 | npn avalanche 150v 0.1A | |
| 415 | FMMT415 | Zet | N | SOT23 | npn avalanche 260v 0.1A | |
| 417 | FMMT417 | Zet | N | SOT23 | npn avalanche 320v 0.1A | |
| 431 | PZM4.3NB1 | Phi | C | SOT346 | 4.3V 0.3W zener | |
| 432 | PZM4.3NB2 | Phi | C | SOT346 | 4.3V 0.3W zener | |
| 433 | PZM4.3NB3 | Phi | C | SOT346 | 4.3V 0.3W zener | |
| 449 | FMMT449 | Zet | N | SOT23 | npn 50V 1A low Vce sat | |
| 451 | FMMT451 | Zet | N | SOT23 | npn 60V 1A | |
| 455 | FMMT455 | Zet | N | SOT23 | NPN 140V 1A | |
| 458 | FMMT458 | Zet | N | SOT23 | npn 400V 0.4A | |
| 471 | PZM4.7NB1 | Phi | C | SOT346 | 4.7V 0.3W zener | |
| 472 | PZM4.7NB2 | Phi | C | SOT346 | 4.7V 0.3W zener | |
| 473 | PZM4.7NB3 | Phi | C | SOT346 | 4.7V 0.3W zener | |
| 491 | FMMT491 | Zet | N | SOT23 | ZTX 450/451 | |
| 493 | FMMT493 | Zet | N | SOT23 | ZTX 453 | |
| 494 | FMMT494 | Zet | N | SOT23 | npn 120V 1A | |
| 495 | FMMT495 | Zet | N | SOT23 | npn 170V 1A | |
| 497 | FMMT497 | Zet | N | SOT23 | npn 300V 0.5A | |
| 4A | MMBV109 | Mot | C | SOT23 | MV209 varicap | |
| 4A | FMMV109 | Zet | C | SOT23 | MV209 varicap | |
| 4A | HD3A | Zet | C | — | 75V 100mA sw diode | |
| 4A | BC859A | ITT | N | SOT23 | BC559A | |
| 4Ap | BC859A | Phi | N | SOT23 | BC559A | |
| 4As | BC859AW | Sie | N | SOT323 | BC559A | |
| 4As | BC859A | Sie | N | SOT23 | BC559A | |
| 4A3 | PZM4.3NB2A | Phi | A | SOT346 | dual ca 4.3V Zener | |
| 4A7 | PZM4.7NB2A | Phi | A | SOT346 | dual ca 4.7V Zener | |
| 4AR | BC859AR | Phi | R | SOT23R | BC559A | |
| 4B | MMBV432 | Mot | B | — | dual cc varicap 1.5-45pF | |
| 4B | BC859B | ITT | N | SOT23 | BC559B | |
| 4Bs | BC859B | Sie | N | SOT23 | BC559B | |
| 4Bs | BC859BW | Sie | N | SOT323 | BC559B | |
| 4Bp | BC859B | Phi | N | SOT23 | BC559B | |
| 4Bt | BC859B | Phi | N | SOT23 | BC559B | |
| 4Bt | BC859BW | Phi | N | SOT323 | BC559B | |
| 4B- | BC859BW | Phi | N | SOT323 | BC559B | |
| 4BR | BC859BR | Phi | R | SOT23R | BC559B | |
| 4C | BC859C | ITT | N | SOT23 | BC559C | |
| 4Cs | BC859C | Sie | N | SOT23 | BC559C | |
| 4Cs | BC859CW | Sie | N | SOT323 | BC559C | |
| 4Cp | BC859C | Phi | N | SOT23 | BC559C | |
| 4Ct | BC859C | Phi | N | SOT23 | BC559C | |
| 4Ct | BC859CW | Phi | N | SOT323 | BC559C | |
| 4C- | BC859CW | Phi | N | SOT323 | BC559C | |
| 4C | MMVB3102 | Mot | C | SOT23 | varicap 6-35pF | |
| 4C | BC859C | Phi | N | SOT23 | BC559C | |
| 4CR | BC859CR | Phi | R | SOT23R | BC559C | |
| 4D | BC859B | Phi | N | SOT23 | BC559B | |
| 4Dt | BC859W | Phi | N | SOT323 | BC559B | |
| 4D- | BC859W | Phi | N | SOT323 | BC559B | |
| 4D | MMBV3401 | Mot | C | SOT23 | VHF pin diode | |
| 4D | HD3A | Zet | C | SOT23 | sw diode 75V 100mA | |
| 4E | BC860A | Phi | N | SOT23 | BC560A | |
| 4E | FMMT-A92 | Zet | N | SOT23 | MPSA92 | |
| 4E | MMBV105G | Mot | C | SOT23 | MV105 varicap | |
| 4ER | BC860AR | Phi | R | SOT23R | BC560A | |
| 4F | MMBD353 | Mot | Z | SOT23 | dual MBD101 | |
| 4F | BC860B | Phi | N | SOT23 | BC560B | |
| 4F | Gali-4F | MC | AZ | SOT89 | DC-4GHz MMIC amp 15 dBm o/p | |
| 4Fs | BC860B | Sie | N | SOT23 | BC560B | |
| 4Fs | BC860BW | Sie | N | SOT323 | BC560B | |
| 4Fp | BC860B | Phi | N | SOT23 | BC560B | |
| 4Ft | BC860B | Phi | N | SOT23 | BC560B | |
| 4Ft | BC860BW | Phi | N | SOT323 | BC560B | |
| 4F- | BC860BW | Phi | N | SOT323 | BC560B | |
| 4FR | BC860BR | Phi | R | SOT23 | BC560B | |
| 4G | MMBV2101 | Mot | C | SOT23 | MV2101 varicap | |
| 4G | BC860C | Phi | N | SOT23 | BC560C | |
| 4Gs | BC860C | Sie | N | SOT23 | BC560C | |
| 4Gs | BC860CW | Sie | N | SOT323 | BC560C | |
| 4Gp | BC860C | Phi | N | SOT23 | BC560C | |
| 4Gt | BC860C | Phi | N | SOT23 | BC560C | |
| 4Gt | BC860CW | Phi | N | SOT323 | BC560C | |
| 4G- | BC860CW | Phi | N | SOT323 | BC560C | |
| 4GR | BC860CR | Phi | R | SOT23 | BC560CR | |
| 4H | MMBV2103 | Mot | C | SOT23 | MV2103 varicap | |
| 4Hp | BC860 | Phi | N | SOT23 | BC560 | |
| 4Ht | BC860W | Phi | N | SOT323 | BC560 | |
| 4H- | BC860W | Phi | N | SOT323 | BC560 | |
| 4J | FMMT38A | Zet | N | SOT23 | BCX38A | |
| 4J | MMBV2109 | Mot | C | SOT23 | MV2109 varicap | |
| 4K | BAP64-04 | Phi | D | — | dual series 3GHz pin diode | |
| 4K | MMSB3000 | Mot | I | SOD123 | Si diode 30V 0.2A | |
| 4L | BAP50-04 | Phi | D | — | dual series GP RF pin diode | |
| 4M | MMBD101 | Mot | C | SOT23 | MBD101 schottky diode | |
| 4Ms | BAT240A | Sie | EQ | SOT143 | dual schottky 250V 0.4A | |
| 4R | MMBV3700 | Mot | C | SOT23 | 200V vhf pin diode | |
| 4S | MMBD201 | Mot | C | SOT23 | MBD201 | |
| 4T | MMBD301 | Mot | C | SOT23 | MBD301 UHF schottky diode | |
| 4U | MMBV2105 | Mot | C | SOT23 | MV2105 varicap | |
| 4V | MMBV2106 | Mot | C | SOT23 | MV2106 varicap | |
| 4V | BCW65AR | Zet | R | SOT23R | npn 32V 0.8A | |
| 4V3 | PZM4.3NB | Phi | C | SOT346 | 4.3V 0.3W zener | |
| 4V7 | PZM4.7NB | Phi | C | SOT346 | 4.7V 0.3W zener | |
| 4W | MMBV2107 | Mot | C | SOT23 | MV2107 varicap | |
| 4W | BCW67AR | Zet | R | SOT23R | pnp 32V 0.8A | |
| 4Y | MMBV2102 | Mot | C | SOT23 | MV2102 varicap | |
| 4Y3 | BZV49-C4V3 | Phi | O | SOT89 | 4.3V 1W zener | |
| 4Y7 | BZV49-C4V7 | Phi | O | SOT89 | 4.7V 1W zener | |
| 4X | MMBV2108 | Mot | C | SOT23 | MV2108 varicap | |
| 4Z | MMBV2104 | Mot | C | SOT23 | MV2104 varicap | |
| Коды на ‘5’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 5 (white) | BAT60B | Sie | I | 10V 3A sw Schottky | ||
| 5 (red) | BBY57-03W | Sie | I | SOD323 | varicap | |
| 500 | SSTPAD500 | Sil | J | PAD-500 500pA leakage diode | ||
| 51 | BAT15-115S | Sie | CS | SOT173 | 40GHz schottky diode | |
| 51 | BAT15-115R | Sie | CZ | SOT173 | 40GHz schottky ring quad | |
| 51D | BAT15-115D | Sie | CY | SOT173 | 40GHz schottky dual | |
| 51V | PZM51NB | Phi | C | SOT346 | 51V 0.3W zener | |
| 51Y | BZV49-C51 | Phi | O | SOT89 | 51V 1W zener | |
| 52 | BAT15-025S | Sie | CS | SOT173 | 4GHz schottky diode | |
| 52 | BAT15-025R | Sie | CZ | SOT173 | 4GHz schottky ring quad | |
| 52 | Gali-52 | MC | AZ | SOT89 | DC-2GHz MMIC amp 23 dB gain | |
| 52 | BAS52-02V | Inf | I | SC79 | Schottky diode 45V 750mA | |
| 52 | DTA123YE | Roh | N | EMT3 | pnp dtr 2k2 +10k 50V 100mA | |
| 52 | DTA123YUA | Roh | N | SC70 | pnp dtr 2k2 +10k 50V 100mA | |
| 52 | DTA123YKA | Roh | N | SC59 | pnp dtr 2k2 +10k 50V 100mA | |
| 52D | BAT15-025D | Sie | CY | SOT173 | 4GHz schottky dual | |
| 53s | BAT17 | Sie | C | SOT23 | schottky diode 4V 100mA | |
| 54 | DTA114YE | Roh | N | EMT3 | pnp dtr 10k + 47k 50V 100mA | |
| 54 | DTA114YUA | Roh | N | SC70 | pnp dtr 10k + 47k 50V 100mA | |
| 54 | DTA114YKA | Roh | N | SC59 | pnp dtr 10k + 47k 50V 100mA | |
| 54s | BAT17-04 | Sie | D | SOT23 | dual series BAT17 | |
| 54s | BAT17-04W | Sie | D | SOT323 | dual series BAT17 | |
| 55 | BAT15-055S | Sie | CS | SOT173 | 8GHz schottky diode | |
| 55 | BAT15-055R | Sie | CZ | SOT173 | 8GHz schottky ring quad | |
| 55 | Gali-55 | MC | AZ | SOT89 | DC-4GHz MMIC amp 21 dB gain | |
| 55D | BAT15-055D | Sie | CY | SOT173 | 8GHz schottky dual | |
| 55s | BAT17-05 | Sie | A | SOT23 | dual ca BAT17 | |
| 55s | BAT17-05W | Sie | A | SOT323 | dual ca BAT17 | |
| 56s | BAT17-06 | Sie | B | SOT23 | dual cc BAT17 | |
| 56s | BAT17-06W | Sie | B | SOT323 | dual cc BAT17 | |
| 56V | PZM56NB | Phi | C | SOT346 | 56V 0.3W zener | |
| 56Y | BZV49-C56 | Phi | O | SOT89 | 56V 1W zener | |
| 57s | BAT17-07 | Sie | S | SOT143 | dual BAT17 | |
| 57 | BFQ57 | Sie | CX | SOT173 | npn 6.5GHz 16V/35mA | |
| 58 | BFQ58 | Sie | CX | SOT173 | npn 6.5GHz 16V/30mA | |
| 59 | BAT15-095S | Sie | CS | SOT173 | 18GHz schottky diode | |
| 59 | BAT15-095R | Sie | CZ | SOT173 | 18GHz schottky ring quad | |
| 59D | BAT15-095D | Sie | CY | SOT173 | 18GHz schottky dual | |
| 511 | PZM5.1NB1 | Phi | C | SOT346 | 5.1V 0.3W zener | |
| 512 | PZM5.1NB2 | Phi | C | SOT346 | 5.1V 0.3W zener | |
| 513 | PZM5.1NB3 | Phi | C | SOT346 | 5.1V 0.3W zener | |
| 561 | PZM5.1NB1 | Phi | C | SOT346 | 5.6V 0.3W zener | |
| 562 | PZM5.1NB2 | Phi | C | SOT346 | 5.6V 0.3W zener | |
| 563 | PZM5.1NB3 | Phi | C | SOT346 | 5.6V 0.3W zener | |
| 558 | FMMT558 | Zet | N | SOT23 | pnp 400V 0.15A | |
| 589 | FMMT589 | Zet | N | SOT23 | pnp 30V 1A | |
| 591 | FMMT591 | Zet | N | SOT23 | ZTX550/551 | |
| 593 | FMMT593 | Zet | N | SOT23 | ZTX 553 | |
| 5A | BC807-16 | Phi | N | SOT23 | BC327-16 | |
| 5As | BC807-16 | Sie | N | SOT23 | BC327-16 | |
| 5As | BC807-16W | Sie | N | SOT323 | BC327-16 | |
| 5Ap | BC807-16 | Phi | N | SOT23 | BC327-16 | |
| 5At | BC807-16 | Phi | N | SOT23 | BC327-16 | |
| 5At | BC807-16W | Phi | N | SOT323 | BC327-16 | |
| 5A- | BC807-16W | Phi | N | SOT323 | BC327-16 | |
| 5A | BSS123 | Mot | M | SOT23 | n-ch tmosfet Vds 100V | |
| 5A | MMBD6050 | Mot | C | SOT23 | sw diode 70V 0.2A | |
| 5A | FMMD6050 | Zet | C | SOT23 | sw diode 70V 100mA | |
| 5A1 | PZM5.1NB2A | Phi | A | SOT346 | dual ca 5.1V 0.3W zener | |
| 5A6 | PZM5.6NB2A | Phi | A | SOT346 | dual ca 5.6V 0.3W zener | |
| 5AR | BC807-16R | Phi | R | SOT23R | BC327-16 | |
| 5B | MMBT4123 | Mot | N | SOT23 | 2N4123 | |
| 5B | BC807-25 | SGS | N | SOT23 | BC327-25 | |
| 5Bs | BC807-25 | Sie | N | SOT23 | BC327-25 | |
| 5Bs | BC807-25W | Sie | N | SOT323 | BC327-25 | |
| 5Bs | BC807-25U | Sie | N | SC74 | BC327-25 | |
| 5Bp | BC807-25 | Phi | N | SOT23 | BC327-25 | |
| 5Bt | BC807-25 | Phi | N | SOT23 | BC327-25 | |
| 5Bt | BC807-25W | Phi | N | SOT323 | BC327-25 | |
| 5B- | BC807-25W | Phi | N | SOT323 | BC327-25 | |
| 5B | MMBD6100 | Mot | B | SOT23 | cc dual diode 70V 0.2A | |
| 5B | FMMD6100 | Zet | B | SOT23 | cc dual diode 70V 0.2A | |
| 5BM | MMBD6100 | Mot | B | SOT23 | cc dual diode 70V 0.2A | |
| 5BR | BC807-25R | Phi | R | SOT23R | BC327-25 | |
| 5C | BC807-40 | SGS | N | SOT23 | BC327-40 | |
| 5Cs | BC807-40 | Sie | N | SOT23 | BC327-40 | |
| 5Cs | BC807-40W | Sie | N | SOT323 | BC327-40 | |
| 5Cp | BC807-40 | Phi | N | SOT23 | BC327-40 | |
| 5Ct | BC807-40 | Phi | N | SOT23 | BC327-40 | |
| 5Ct | BC807-40W | Phi | N | SOT323 | BC327-40 | |
| 5C- | BC807-40W | Phi | N | SOT323 | BC327-40 | |
| 5C | MMBD7000 | Mot | D | SOT23 | 2 ser diodes 100V 0.2A | |
| 5C | FMMD7000 | Zet | D | SOT23 | 2 ser diodes 70V 200mA | |
| 5CR | BC807-40R | Phi | R | SOT23E | BC327-40 | |
| 5D | FMMD914 | Zet | C | SOT23 | 1N914 | |
| 5D | MMBD914 | Mot | C | SOT23 | 1N914 | |
| 5D | MMSD914 | Mot | I | SOD123 | 1N914 | |
| 5D | HD2A | Zet | B | dual cc HD2 75V 100mA | ||
| 5Dp | BC807 | Phi | N | SOT23 | BC327 | |
| 5Dt | BC807 | Phi | N | SOT23 | BC327 | |
| 5Dt | BC807W | Phi | N | SOT323 | BC327 | |
| 5D- | BC807W | Phi | N | SOT323 | BC327 | |
| 5E | BC808-16 | Phi | N | SOT23 | BC328-16 | |
| 5Es | BC808-16 | Sie | N | SOT23 | BC328-16 | |
| 5Es | BC808-16W | Sie | N | SOT323 | BC328-16 | |
| 5E | FMMT-A43R | Zet | R | SOT23R | MPSA43 | |
| 5E | BC808-16 | Phi | N | SOT23 | BC328-16 | |
| 5ER | BC808-16R | Phi | R | SOT23R | BC328-16 | |
| 5F | BC808-25 | Phi | N | SOT23 | BC328-25 | |
| 5Fs | BC808-25 | Sie | N | SOT23 | BC328-25 | |
| 5Fs | BC808-25W | Sie | N | SOT323 | BC328-25 | |
| 5F | MMBD501 | Mot | C | SOT23 | MBD501 hot carrier diode | |
| 5F | Gali-5F | MC | AZ | SOT89 | DC-4GHz MMIC amp 20 dB gain | |
| 5FR | BC808-25R | Phi | R | SOT23R | BC328-25 | |
| 5G | BC808-40 | Phi | N | SOT23 | BC328-40 | |
| 5Gs | BC808-40 | Sie | N | SOT23 | BC328-40 | |
| 5Gs | BC808-40W | Sie | N | SOT323 | BC328-40 | |
| 5G | MMBD353 | Mot | D | dual series MBD101 | ||
| 5GR | BC808-40R | Phi | R | SOT23R | BC328-40 | |
| 5H | MMBD701 | Mot | C | SOT23 | MBD701 UHF schottky diode | |
| 5Hp | BC808 | Phi | N | SOT23 | BC328 | |
| 5HZ | BC808 | Zet | N | SOT23 | BC328 | |
| 5H | MMBD4148 | Nat | C | SOT23 | 1N4148 | |
| 5I | MMSD4148 | Mot | C | 1N4148 | ||
| 5J | FMMT38B | Zet | N | BCX38B | ||
| 5K | MMBV809 | Mot | C | SOT23 | Hyperabrupt varicap | |
| 5Kp | BAP64-05 | Phi | B | dual cc 3GHz RF pin diode | ||
| 5L | MMBV609 | Mot | B | SOT23 | dual cc Hyperabrupt varicap | |
| 5N | MMBD452L | Mot | D | SOT23 | series UHF schottky diodes | |
| 5P | FMMT2907AR | Zet | R | SOT23R | 2N2907A | |
| 5T | BCW66GR | Sie | R | SOT23R | npn 45V 0.8A 350mW | |
| 5V | BCW65BR | Zet | R | SOT23R | npn 32V 0.8A | |
| 5V1 | PZM5.1NB | Phi | C | SOT346 | 5.1V 0.3W zener | |
| 5V6 | PZM5.6NB | Phi | C | SOT346 | 5.6V 0.3W zener | |
| 5W | BCW67BR | Zet | R | SOT23R | pnp 32V 0.8A | |
| 5Y1 | BZV49-C5V1 | Phi | O | SOT89 | 5.1V 1W zener | |
| 5Y6 | BZV49-C5V6 | Phi | O | SOT89 | 5.6V 1W zener | |
| Коды на ‘6’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 6 (red) | BBY56-03W | Sie | I | SOD323 | varicap | |
| 60s | BAR60 | Sie | SOT143 | 3 pin diodes | ||
| 605 | NDS0605 | Fch | M | SOT23 | P-ch mosfet 60V 180mA | |
| 61s | BAR61 | Sie | PQ | SOT143 | 3 pin diodes pi atten | |
| 61A | MMBF4117 | Nat | F | — | n-ch jfet ultra low i/p Ig | |
| 61C | MMBF4118 | Nat | F | — | n-ch jfet ultra low i/p Ig | |
| 61A | MMBF4119 | Nat | F | — | n-ch jfet ultra low i/p Ig | |
| 61J | MMBF4091 | Nat | F | — | n-ch jfet sw/chopper | |
| 61K | MMBF4092 | Nat | F | — | n-ch jfet sw/chopper | |
| 61L | MMBF4093 | Nat | F | — | n-ch jfet sw/chopper | |
| 61M | MMBF4859 | Nat | F | — | n-ch jfet sw/chopper | |
| 61N | MMBF5514 | Nat | F | — | p-ch jfet sw/chopper | |
| 61P | MMBF5115 | Nat | F | — | p-ch jfet sw/chopper | |
| 61Q | MMBF5516 | Nat | F | — | p-ch jfet sw/chopper | |
| 61S | MMBF5458 | Nat | F | — | n-ch jfet gp 2N5458 | |
| 61T | MMBF5459 | Nat | F | — | n-ch jfet gp 2N5459 | |
| 61U | MMBF5461 | Nat | F | — | p-ch jfet gp 2N5461 | |
| 61V | MMBF5462 | Nat | F | — | p-ch jfet gp 2N5462 | |
| 62 | DTC123YE | Roh | N | EMT3 | npn dtr 2k2 +10k 50V 100mA | |
| 62 | DTC123YUA | Roh | N | SC70 | npn dtr 2k2 +10k 50V 100mA | |
| 62 | DTC123YKA | Roh | N | SC59 | npn dtr 2k2 +10k 50V 100mA | |
| 62P | MMBFJ201 | Nat | F | — | n-ch jfet gp J201 | |
| 62Q | MMBFJ202 | Nat | F | — | n-ch jfet gp J202 | |
| 62R | MMBFJ203 | Nat | F | — | n-ch jfet gp J203 | |
| 62S | MMBFJ270 | Nat | F | — | p-ch jfet gp J270 | |
| 62T | MMBFJ271 | Nat | F | — | p-ch jfet gp J271 | |
| 62V | PZM62NB1 | Phi | C | SOT346 | 62V 0.3W zener | |
| 62Y | BZV49-C62 | Phi | O | SOT89 | 62V 1W zener | |
| 63s | BAT64 | Sie | C | SOT23 | Schottky 40V 250mA gp | |
| 63s | BAT64W | Sie | C | SOT323 | Schottky 40V 250mA gp | |
| 63Q | MMBFJ304 | Nat | F | — | n-ch jfet vhf J304 | |
| 64 | DTC114YE | Roh | N | EMT3 | npn dtr 10k + 47k 50V 100mA | |
| 64 | DTC114YUA | Roh | N | SC70 | npn dtr 10k + 47k 50V 100mA | |
| 64 | DTC114YKA | Roh | N | SC59 | npn dtr 10k + 47k 50V 100mA | |
| 64s | BAT64-04 | Sie | D | SOT23 | dual ser gp Schottky 40V 250mA | |
| 64s | BAT64-04W | Sie | D | SOT323 | dual ser gp Schottky 40V 250mA | |
| 65s | BAT64-05 | Sie | B | SOT23 | dual cc gp Schottky 40V 250mA | |
| 65s | BAT64-05W | Sie | B | SOT323 | dual cc gp Schottky 40V 250mA | |
| 66s | BAT64-06 | Sie | A | SOT23 | dual ca gp Schottky 40V 250mA | |
| 66s | BAT64-06W | Sie | A | SOT323 | dual ca gp Schottky 40V 250mA | |
| 67s | BAT64-07 | Sie | S | SOT143 | dual gp Schottky 40V 250mA | |
| 67s | BAT64-07W | Sie | S | SOT343 | dual gp Schottky 40V 250mA | |
| 67 | BFP67 | Tfk | X | — | npn Rf fT 7.5GHz 10V 50mA | |
| 67R | BFP67R | Tfk | WQ | — | npn Rf fT 7.5GHz 10V 50mA | |
| 68Y | BZV49-C68 | Phi | O | SOT89 | 68V 1W zener | |
| 68V | PZM68NB1 | Phi | C | SOT346 | 68V 0.3W zener | |
| 69 | DTA114YE | Mot | N | SOT416 | pnp dtr 10k +47k | |
| 69 | DTC115EE | Roh | N | EMT3 | npn dtr 100k+100k 50V 20mA | |
| 69 | DTC115EUA | Roh | N | SC70 | npn dtr 100k+100k 50V 20mA | |
| 69 | DTC115EKA | Roh | N | SC59 | npn dtr 100k+100k 50V 20mA | |
| 605 | NDS0605 | Fch | M | — | p-ch sw mosfet 60V | |
| 610 | NDS0610 | Fch | M | — | p-ch sw mosfet 60V | |
| 614 | FMMT614 | Zet | N | SOT23 | sw | |
| 617 | FMMT617 | Zet | N | SOT23 | npn sw 15V 3A | |
| 618 | FMMT618 | Zet | N | SOT23 | npn sw 20V 2.5A | |
| 619 | FMMT619 | Zet | N | SOT23 | npn sw 50V 2A | |
| 621 | PZM6.2NB1 | Phi | C | SOT346 | 6.2V 0.3W zener | |
| 622 | PZM6.2NB2 | Phi | C | SOT346 | 6.2V 0.3W zener | |
| 623 | PZM6.2NB3 | Phi | C | SOT346 | 6.2V 0.3W zener | |
| 624 | FMMT624 | Zet | N | SOT23 | — | |
| 625 | FMMT625 | Zet | N | SOT23 | — | |
| 634 | FMMT634 | Zet | N | SOT23 | 100V 0.9A darlington npn | |
| 651 | PZT651 | Mot | N | SOT223 | npn 60V 1A | |
| 681 | PZM6.8NB1 | Phi | C | SOT346 | 6.8V 0.3W zener | |
| 682 | PZM6.8NB2 | Phi | C | SOT346 | 6.8V 0.3W zener | |
| 683 | PZM6.8NB1 | Phi | C | SOT346 | 6.8V 0.3W zener | |
| 6A | MMBF4416 | Mot | F | SOT23 | 2N4416 n-ch vhf jfet | |
| 6A | MUN2111 | Mot | N | SOT23 | pnp dtr with 10k+10k | |
| 6A | MUN5111 | Mot | N | SOT323 | pnp dtr with 10k+10k | |
| 6A | BC817-16 | Phi | N | SOT23 | BC337-16 | |
| 6As | BC817-16 | Sie | N | SOT23 | BC337-16 | |
| 6As | BC817-16 | Sie | N | SOT323 | BC337-16 | |
| 6Ap | BC817-16W | Phi | N | SOT23 | BC337-16 | |
| 6At | BC817-16 | Phi | N | SOT23 | BC337-16 | |
| 6At | BC817-16W | Phi | N | SOT323 | BC337-16 | |
| 6A- | BC817-16W | Phi | N | SOT323 | BC337-16 | |
| 6A2 | PZM6.2NB2A | Phi | A | SOT346 | dual ca 6.2V 0.3W zener | |
| 6A8 | PZM6.8NB2A | Phi | A | SOT346 | dual ca 6.8V 0.3W zener | |
| 6AR | BC817-16R | Phi | R | SOT23 | BC337-16 | |
| 6AZ | BC817-16 | Zet | N | SOT23 | BC337-16 | |
| 6B | MMBF5484 | Mot | F | SOT23 | n-ch jfet 2N5484 | |
| 6B | BC817-25 | Phi | N | SOT23 | BC337-25 | |
| 6Bs | BC817-25 | Sie | N | SOT23 | BC337-25 | |
| 6Bs | BC817-25W | Sie | N | SOT323 | BC337-25 | |
| 6Bp | BC817-25 | Phi | N | SOT23 | BC337-25 | |
| 6Bt | BC817-25 | Phi | N | SOT23 | BC337-25 | |
| 6Bt | BC817-25W | Phi | N | SOT323 | BC337-25 | |
| 6B- | BC817-25W | Phi | N | SOT323 | BC337-25 | |
| 6B | MUN2112 | Mot | N | SOT23 | pnp dtr 22k+22k | |
| 6B | MUN5112 | Mot | N | SOT323 | MUN2112 | |
| 6BR | BC817-25R | Phi | R | SOT23R | BC337-25 | |
| 6BZ | BC817-25 | Zet | N | SOT23 | BC337-25 | |
| 6C | BC817-40 | Phi | N | SOT23 | BC337-40 | |
| 6Cs | BC817-40 | Sie | N | SOT23 | BC337-40 | |
| 6Cs | BC817-40W | Sie | N | SOT323 | BC337-40 | |
| 6Cp | BC817-40 | Phi | N | SOT23 | BC337-40 | |
| 6Ct | BC817-40 | Phi | N | SOT23 | BC337-40 | |
| 6Ct | BC817-40W | Phi | N | SOT323 | BC337-40 | |
| 6C- | BC817-40W | Phi | N | SOT323 | BC337-40 | |
| 6C | MMBFU310 | Mot | F | SOT23 | n-ch jfet U310 | |
| 6C | MUN2113 | Mot | N | SOT23 | pnp dtr 47k+47k | |
| 6C | MUN5113 | Mot | N | SOT323 | MUN2113 | |
| 6CR | BC817-40R | Phi | R | SOT23R | BC337-40 | |
| 6CZ | BC817-40 | Zet | N | SOT23 | BC337-40 | |
| 6Dp | BC817 | Phi | N | SOT23 | BC337 | |
| 6Dt | BC817 | Phi | N | SOT23 | BC337 | |
| 6Dt | BC817W | Phi | N | SOT323 | BC337 | |
| 6D- | BC817W | Phi | N | SOT323 | BC337 | |
| 6D | MMBF5457 | Mot | F | SOT23 | 2N5457 n-ch jfet | |
| 6D | MUN2114 | Mot | N | SOT23 | pnp dtr 10k+47k | |
| 6D | MUN5114 | Mot | N | SOT323 | MUN21141 | |
| 6DZ | BC817 | Zet | N | SOT23 | BC337 | |
| 6E | FMMT-A93R | Zet | R | SOT23R | MPSA93 | |
| 6E | MMBF5460 | Mot | F | SOT23 | p-ch jfet 2N5460 | |
| 6E | BC818-16 | Phi | N | SOT23 | BC338-16 | |
| 6Es | BC818-16 | Sie | N | SOT23 | BC338-16 | |
| 6Es | BC818-16W | Sie | N | SOT323 | BC338-16 | |
| 6E | MUN2115 | Mot | N | SOT23 | pnp dtr R1 10k | |
| 6E | MUN5115 | Mot | N | SOT323 | MUN2115 | |
| 6ER | BC818-16R | Phi | R | SOT23 | BC338-16 | |
| 6EZ | BC818-16 | Zet | N | SOT23 | BC338-16 | |
| 6F | MMBF4860 | Mot | F | SOT23 | 2N4860 n-ch jfet | |
| 6F | BC818-25 | Phi | N | SOT23 | BC338-25 | |
| 6Fs | BC818-25 | Sie | N | SOT23 | BC338-25 | |
| 6Fs | BC818-25W | Sie | N | SOT323 | BC338-25 | |
| 6F | MUN2116 | Mot | N | SOT23 | pnp dtr R1 4k7 | |
| 6F | MUN5116 | Mot | N | SOT323 | MUN2116 | |
| 6F | Gali-6F | MC | AZ | SOT89 | DC-4GHz MMIC amp 12 dB gain | |
| 6FR | BC818-25R | Phi | R | SOT23R | BC338-25 | |
| 6FZ | BC818-25 | Zet | N | SOT23 | BC338-25 | |
| 6G | BC818-40 | Phi | N | SOT23 | BC338-40 | |
| 6Gs | BC818-40 | Sie | N | SOT23 | BC338-40 | |
| 6Gs | BC818-40W | Sie | N | SOT323 | BC338-40 | |
| 6G | MMBF4393 | Mot | F | SOT23 | n-ch jfet 2N4393 | |
| 6G | MUN2130 | Mot | N | SOT23 | pnp dtr 1k0+1k0 | |
| 6G | MUN5130 | Mot | N | SOT323 | ial»>MUN2130 | |
| 6GR | BC818-40R | Phi | R | SOT23 | BC338-40 | |
| 6GZ | BC818-40 | Zet | N | SOT23 | BC338-40 | |
| p6G | PMBF4393 | Phi | F | SOT23 | n-ch jfet 2N4393 | |
| 6Hp | BC818 | Phi | N | SOT23 | BC338 | |
| 6HZ | BC818 | Zet | N | SOT23 | BC338 | |
| 6H | MMBF5486 | Mot | F | SOT23 | n-ch jfet 2N5486 | |
| 6H | MUN2131 | Mot | N | SOT23 | pnp dtr 2k2 +2k2 | |
| 6H | MUN5131 | Mot | N | SOT323 | MUN2121 | |
| 6J | MMBF4391 | Mot | F | SOT23 | n-ch jfet 2N4391 | |
| 6J | MUN2132 | Mot | N | SOT23 | pnp dtr 4k7+ 4k7 | |
| 6J | MUN5132 | Mot | N | SOT323 | MUN2132 | |
| p6J | MMBF4391 | Phi | F | SOT23 | n-ch jfet 2N4391 | |
| 6K | MMBF4932 | Mot | F | SOT23 | n-ch jfet 2N4932 | |
| 6K | MUN2133 | Mot | N | SOT23 | pnp dtr 4k7+ 47k | |
| 6K | MUN5133 | Mot | N | SOT323 | MUN2133 | |
| p6K | MMBF4932 | Phi | F | SOT23 | n-ch jfet 2N4932 | |
| 6L | MMBF5459 | Mot | F | SOT23 | n-ch jfet 2N5459 | |
| 6L | MUN2134 | Mot | N | SOT23 | pnp dtr 22k+47k | |
| 6L | MUN5134 | Mot | N | SOT323 | MUN2134 | |
| 6M | MMBF5485 | Nat | F | SOT23 | n-ch jfet vhf 2N5485 | |
| 6N | MMBF4861 | Nat | F | SOT23 | n-ch jfet sw/chopper | |
| 6Q | MMBFJ305 | Nat | F | — | n-chjfet vhf J305 | |
| 6P | MMBFJ111 | Nat | F | — | J111 n-ch jfet | |
| 6P | BCX71HR | Phi | R | SOT23R | BCX79 | |
| 6R | MMBFJ112 | Nat | F | — | J112 n-chjfet | |
| 6P | MMBFJ113 | Nat | F | — | J113 n-ch jfet | |
| 6S | MMBFJ176 | Nat | F | — | J176 n-ch jfet | |
| 6S | MMSD71 | Mot | C | — | gp Si diode | |
| p6S | PMBFJ176 | Phi | F | — | J176 n-ch jfet | |
| 6T | BCW68GR | Sie | R | — | pnp 45V 0.8A 350mW | |
| 6T | MMBFJ310 | Mot | F | SOT23 | uhf n-ch jfet J310 | |
| 6U | MMBFJ309 | Nat | F | SOT23 | uhf n-ch jfet J309 | |
| 6V | BCW65CR | Zet | R | SOT23R | npn 32V 0.8A | |
| 6V | MMBFJ174 | Nat | F | — | J174 p-ch jfet sw/chopper | |
| 6V2 | PZM6.2NB | Phi | C | SOT346 | 6.2V 0.3W zener | |
| 6V8 | PZM6.8NB | Phi | C | SOT346 | 6.8V 0.3W zener | |
| 6W | BCW67CR | Zet | R | SOT23R | pnp32V 0.8A | |
| 6W | MMBFJ175 | Mot | F | SOT23 | J175 p-ch jfet | |
| p6W | PMBFJ175 | Phi | F | SOT23 | J175 p-ch jfet | |
| 6X | MMBFJ174 | Nat | F | — | J174 p-ch jfet sw/chopper | |
| p6X | PMBFJ174 | Phi | F | — | J174 p-ch jfet sw/chopper | |
| 6Y | MMBFJ177 | Mot | F | SOT23 | J177 p-ch jfet | |
| p6Y | PMBFJ177 | Phi | F | SOT23 | J177 p-ch jfet | |
| 6Y2 | BZV49-C6V2 | Phi | O | SOT89 | 6.2V 1W zener | |
| 6Y8 | BZV49-C6V8 | Phi | O | SOT89 | 6.8V 1W zener | |
| 6Z | MMBF170 | Mot | M | SOT23 | tmosfet n-ch Vds 60V | |
| Коды на ‘7’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 7 (white) | BBY55-02W | Sie | I | SCD80 | UHF Varicap | |
| 70 | BFQ70 | Sie | CX | SOT173 | npn fT 5.2GHz 15V 35mA | |
| 71 | BFQ71 | Sie | CX | SOT173 | npn fT 5.2GHz 15V 30mA | |
| 72 | BFQ72 | Sie | CX | SOT173 | npn fT 5.1GHz 15V 50mA | |
| 72 | 2N7002 | Sil | M | SOT23 | n-ch mosfet 60V 170mA | |
| 73s | BAS70 | Sie | C | SOT23 | schottky diode 70V 50mA | |
| 73p | BAS70 | Phi | C | SOT23 | schottky diode 70V 50mA | |
| 73t | BAS70 | Phi | C | SOT23 | schottky diode 70V 50mA | |
| 73t | BAS70W | Phi | C | SOT323 | schottky diode 70V 50mA | |
| 73- | BAS70W | Phi | C | SOT323 | schottky diode 70V 50mA | |
| 73 | MA4CS101A | M/A | C | SOT23 | schottky diode 70V 50mA | |
| 73 | BFQ73 | Sie | CX | SOT173 | npn fT 4.9GHz 15V 75mA | |
| 73 | 2SC5004 | Nec | N | — | npn RF 5GHz @5V 5mA | |
| 73S | BFQ73S | Sie | CX | SOT173 | npn fT 5.3GHz 15V 100mA | |
| 74 | BFQ74 | Sie | CX | SOT173 | npn fT 6GHz 16V 35mA | |
| 74s | BAS70-04 | Sie | D | SOT23 | dual series BAS70 | |
| 74p | BAS70-04 | Phi | D | SOT23 | dual series BAS70 | |
| 74t | BAS70-04 | Phi | D | SOT23 | dual series BAS70 | |
| 74t | BAS70-04W | Phi | D | SOT323 | dual series BAS70 | |
| 74t | BAS70-04W | Phi | D | SOT323 | dual series BAS70 | |
| 74 | MA4CS101B | M/A | D | SOT23 | dual series MA4CS101A (73) | |
| 74 | DTA114WE | Rho | N | EMT3 | pnp dtr 10k + 4k7 50V 100mA | |
| 74 | DTA114WUA | Rho | N | SC70 | pnp dtr 10k + 4k7 50V 100mA | |
| 74 | DTA114WKA | Rho | N | SC59 | pnp dtr 10k + 4k7 50V 100mA | |
| 74 | 2SC5005 | Nec | N | — | npn RF 5.5GHz @5V 5mA | |
| 75s | BAS70-05 | Sie | B | SOT23 | dual cc BAS70 | |
| 75s | BAS70-05W | Sie | B | SOT323 | dual cc BAS70 | |
| 75p | BAS70-05 | Phi | B | SOT23 | dual cc BAS70 | |
| 75t | BAS70-05W | Phi | B | SOT323 | dual cc BAS70 | |
| 75t | BAS70-05 | Phi | B | SOT23 | dual cc BAS70 | |
| 75- | BAS70-05W | Phi | B | SOT323 | dual cc BAS70 | |
| 75 | BFQ75 | Sie | CX | SOT173 | pnp fT 5GHz 12V 50mA | |
| 75Y | BZV49-C75 | Phi | O | SOT89 | 75V 1W zener | |
| 76s | BAS70-06 | Sie | A | SOT23 | dual ca BAS70 | |
| 76p | BAS70-06 | Phi | A | SOT23 | dual ca BAS70 | |
| 76t | BAS70-06 | Phi | A | SOT23 | dual ca BAS70 | |
| 76t | BAS70-06W | Phi | A | SOT323 | dual ca BAS70 | |
| 76- | BAS70-06W | Phi | A | SOT323 | dual ca BAS70 | |
| 76 | BFQ76 | Sie | CX | SOT173 | pnp fT 5GHz 15V 30mA | |
| 76 | DTA144WE | Rho | N | EMT3 | pnp dtr 47k + 22k 50V 30mA | |
| 76 | DTA144WUA | Rho | N | SC70 | pnp dtr 47k + 22k 50V 30mA | |
| 76 | DTA144WKA | Rho | N | SC59 | pnp dtr 47k + 22k 50V 30mA | |
| 77s | BAS70-07 | Sie | S | SOT143 | dual BAS70 | |
| 77s | BAS70-07 | Sie | S | SOT343 | dual BAS70 | |
| 77 | MA4CS101E | M/A | S | SOT143 | dual MA4CS101A (73) | |
| 77 | BFQ77 | Sie | CX | SOT173 | npn fT 7GHz 15V 20mA | |
| 78 | MMBT4258 | Nat | N | SOT23 | pnp sw fT 700MHz | |
| 701 | 2N7001 | Mot | M | SOT23 | n-ch mosfet | |
| 702 | 2N7002 | Mot | M | SOT23 | n-ch mosfet 60V 0.11A | |
| 703 | 2N7003 | Mot | M | SOT23 | n-ch mosfet | |
| 712 | NDS7002A | Nat | M | SOT23 | n-ch mosfet 60V 0.28A | |
| 717 | FMMT717 | Zet | N | SOT23 | pnp sw 0.625W 2.5A 12V | |
| 718 | FMMT718 | Zet | N | SOT23 | pnp sw 0.625W 1.5A 20V | |
| 720 | FMMT720 | Zet | N | SOT23 | pnp sw 0.625W 1.5A | |
| 722 | FMMT722 | Zet | N | SOT23 | pnp sw | |
| 723 | FMMT723 | Zet | N | SOT23 | pnp sw | |
| 751 | PZM7.5NB1 | Phi | C | SOT346 | 7.5V 0.3W zener | |
| 752 | PZM7.5NB2 | Phi | C | SOT346 | 7.5V 0.3W zener | |
| 753 | PZM7.5NB3 | Phi | C | SOT346 | 7.5V 0.3W zener | |
| 7A | MMBR901 | Mot | N | SOT23 | npn RF MRF901 | |
| 7A | MUN5211DW1 | Mot | DN | SOT363 | dual npn dtr 10k+10k | |
| 7A5 | PZM7.5NB2A | Phi | A | SOT346 | dual ca 7.5V 0.3W zener | |
| 7B | MMBR920 | Mot | N | SOT23 | npn RF ?MRF920 | |
| 7B | MUN5212DW1 | Mot | DN | SOT363 | dual npn dtr 22k+22k | |
| 7C | MMBR930 | Mot | N | SOT23 | npn RF ?MRF930 | |
| 7C | MUN5213DW1 | Mot | DN | SOT363 | dual npn dtr 47k+47k | |
| 7D | MMBR931 | Mot | N | SOT23 | npn RF ?MRF931 | |
| 7D | HD4A | Zet | A | — | ca dual HD3A | |
| 7D | MUN5214DW1 | Mot | DN | SOT363 | dual npn dtr 10k+47k | |
| 7E | FMMT-A42R | Zet | R | — | MPSA42 | |
| 7E | MMBR2060 | Mot | N | — | npn RF fT 1GHz Vce 30V 50mA | |
| 7E | MUN5215DW1 | Mot | DN | SOT363 | dual npn 10k base res | |
| 7F | MMBR4957 | Mot | N | — | npn RF fT 1.2GHz 30V 30mA | |
| 7F | MUN5211DW1 | Mot | DN | SOT363 | dual npn dtr R1 4k7 | |
| 7G | MMBR5031 | Mot | N | SOT23 | npn RF fT 1GHz 10V 20mA | |
| 7G | MUN5230DW1 | Mot | DN | SOT363 | dual npn dtr 1k0+1k0 | |
| 7H | MMBR5179 | Mot | N | SOT23 | npn RF 2N5179/BFY90 | |
| 7H | MUN5231DW1 | Mot | DN | SOT363 | dual npn dtr 2k2+2k2 | |
| 7J | FMMT38C | Zet | N | SOT23 | BCX38C | |
| 7J | MUN5232DW1 | Mot | DN | SOT363 | dual npn dtr 4k7+4k7 | |
| 7K | MMBR2857 | Mot | N | — | npn RF fT 1GHz Vce 15V 40mA | |
| 7K | MUN5233DW1 | Mot | DN | SOT363 | dual npn dtr 4k7+47k bias | |
| 7L | MUN5234DW1 | Mot | DN | SOT3636 | dual npn dtr 22k+47k bias | |
| 7M | MUN5235DW1 | Mot | DN | SOT363 | dual npn dtr 2k2+47k bias | |
| 7M | MMBR521L | Mot | N | SOT23 | pnp RF MRF521 | |
| 7M | BCW66HR | Zet | R | SOT23R | npn 45V 0.8A | |
| 7N | MMBR941BL | Mot | N | SOT23 | npn RF fT 8GHx MRF941 | |
| 7N | BCW68HR | Zet | R | SOT23 | pnp 45V 0.8A | |
| 7P | BCW66FR | SGS | R | SOT23R | npn 45V 0.8A 350mW | |
| 7P | MMBR911L | Mot | N | SOT23 | npn RF fT 6GHz MRF911 | |
| 7R | MMBR536 | Mot | N | — | npn RF MRF536 | |
| 7T | BCW68FR | Zet | R | SOT23R | pnp 45V 0.8A | |
| 7V5 | PZM7.5NB | Phi | C | SOT346 | 7.5V 0.3W zener | |
| 7X | MMBR571L | Mot | N | SOT23 | npn RF fT 8GHz MRF571 | |
| 7Y | MMBR941L | Mot | N | SOT23 | npn RF fT 8GHz MRF941 | |
| 7Y5 | BZV49-C7V5 | Phi | O | SOT89 | 7.5V 1W zener | |
| 7Z | MMBR951L | Mot | N | SOT23 | npn RF fT7.5GHz MRF951 | |
| Коды на ‘8’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 8 (yellow) | BBY58-03W | Sie | I | SOD323 | varicap | |
| 81 | ZMV831BV2 | Zet | I | SOD523 | 28V hyperabrupt varicap 15pF @2V | |
| 81A | MMBZ5250B | Mot | C | SOT23 | 20V zener 0.225W | |
| 81A | PMBZ5250B | Phi | C | SOT23 | 20V zener 0.225W | |
| 81B | MMBZ5251B | Mot | C | SOT23 | 22V zener 0.225W | |
| 81B | PMBZ5251B | Phi | C | SOT23 | 22V zener 0.225W | |
| 81C | MMBZ5252B | Mot | C | SOT23 | 24V zener 0.225W | |
| 81C | PMBZ5252B | Phi | C | SOT23 | 24V zener 0.225W | |
| 81D | MMBZ5253B | Mot | C | SOT23 | 25V zener 0.225W | |
| 81D | PMBZ5253B | Phi | C | SOT23 | 25V zener 0.225W | |
| 81E | MMBZ5254B | Mot | C | SOT23 | 27V zener 0.225W | |
| 81E | PMBZ5254B | Mot | C | SOT23 | 27V zener 0.225W | |
| 81F | MMBZ5255B | Mot | C | SOT23 | 28V zener 0.225W | |
| 81F | PMBZ5255B | Sie | C | SOT23 | 28V zener 0.225W | |
| 81G | MMBZ5256B | Mot | C | SOT23 | 30V zener 0.225W | |
| 81G | PMBZ5256B | Phi | C | SOT23 | 30V zener 0.225W | |
| 81H | MMBZ5257B | Mot | C | SOT23 | 33V zener 0.225W | |
| 81H | PMBZ5257B | Phi | C | SOT23 | 33V zener 0.225W | |
| 82 | 2SC5009 | Nec | N | — | npn RF fT 12GHz @ 3V 5mA | |
| 82 | ZMV832BV2 | Zet | I | SOD523 | 28V hyperabrupt varicap 22pF @2V | |
| 82P | BFP182T | Tfk | X | — | npn RF fT 7.5GHz 10V 35mA | |
| 83 | MMBT4400 | Nat | N | — | npn 2N4400 | |
| 83s | BAT68 | Sie | C | SOT23 | gp Schottky 8V 130mA | |
| 83s | BAT68W | Sie | C | SOT323 | gp Schottky 8V 130mA | |
| 83 | 2SC5010 | Nec | N | — | npn RF fT 12GHz 3V 10mA | |
| 83 | MA4CS102A | M/A | C | SOT23 | schottky diode 8V 30mA | |
| 83P | BFP183T | Tfk | X | — | npn RF fT 7.4GHz 10V 65mA | |
| 84s | BAT68-04 | Sie | D | SOT23 | dual ser gp Schottky 8V 130mA | |
| 84s | BAT68-04W | Sie | D | SOT323 | dual ser gp Schottky 8V 130mA | |
| 84 | MA4CS102B | M/A | D | SOT23 | dual ser schottky diode 8V 30mA | |
| 84 | DTC114WE | Rho | N | EMT3 | npn dtr 10k + 4k7 50V 100mA | |
| 84 | DTC114WUA | Rho | N | SC70 | npn dtr 10k + 4k7 50V 100mA | |
| 84 | DTC114WKA | Rho | N | SC59 | npn dtr 10k + 4k7 50V 100mA | |
| 85 | MMBD1701 | Nat | C | — | Fast Si diode 30V 50mA | |
| 85 | MA4CS102A | M/A | B | SOT23 | dual cc schottky diode 8V 30mA | |
| 85s | BAT68-05 | Sie | B | SOT23 | gp dual cc Schottky 8V 130mA | |
| 85s | BAT68-05W | Sie | B | SOT323 | gp dual cc Schottky 8V 130mA | |
| 86 | MMBD1702 | Nat | K | — | Fast Si diode 30V 50mA | |
| 86 | DTC144WE | Rho | N | EMT3 | npn dtr 47k + 22k 50V 30mA | |
| 86 | DTC144WUA | Rho | N | SC70 | npn dtr 47k + 22k 50V 30mA | |
| 86 | DTC144WKA | Rho | N | SC59 | npn dtr 47k + 22k 50V 30mA | |
| 86s | BAT68-06 | Sie | A | SOT23 | gp dual ca Schottky 8V 130mA | |
| 86s | BAT68-06W | Sie | A | SOT323 | gp dual ca Schottky 8V 130mA | |
| 87 | MMBD1703 | Nat | D | — | dual ser MMBD1701 | |
| 87 | MA4CS102A | M/A | S | SOT143 | dual schottky diode 8V 30mA | |
| 87s | BAT68-07 | Sie | S | SOT143 | gp dual schottky 8V 130mA | |
| 88 | MMBD1704 | Nat | B | — | dual cc MMBD1701 | |
| 89 | MMBD1705 | Nat | A | — | dual ca MMBD1701 | |
| 821 | PZM8.2NB1 | Phi | C | SOT23 | 8.2V 0.3W zener | |
| 822 | PZM8.2NB2 | Phi | C | SOT23 | 8.2V 0.3W zener | |
| 822 | S822T | Tfk | X | — | npn RF fT 5.2GHz 6V 8mA | |
| 823 | PZM8.2NB3 | Phi | C | SOT23 | 8.2V 0.3W zener | |
| 852 | S852T | Tfk | N | SOT23 | npn RF fT 5.2GHz 6V 8mA | |
| 887 | S887T | Tfk | W | SOT143 | n-ch dg uhf mosfet | |
| 888 | S888T | Tfk | W | SOT142 | n-ch dg uhf mosfet | |
| 8A | NJM78L02A | NJR | KQ | SOT89 | 78L 2.0V 0.1A regulator | |
| 8A | MMBZ5226B | Mot | C | SOT23 | 3.3V zener 0.225W | |
| 8A | MUN2211 | Mot | N | SOT23 | npn dtr 10k +10k | |
| 8A | MUN5211 | Mot | N | SOT323 | npn dtr 10k +10k | |
| 8A2 | PZM8.2NB2A | Phi | C | SOT23 | dual ca 8.2V 0.3W zener | |
| 8B | NJM78L03A | NJR | KQ | SOT89 | 78L 3.0V 0.1A regulator | |
| 8B | MMBZ5227B | Mot | C | SOT23 | 3.6V zener 0.225W | |
| 8B | MUN2212 | Mot | N | SOT23 | npn dtr 22k+22k | |
| 8B | MUN5212 | Mot | N | SOT323 | npn dtr 22k+22k | |
| 8C | NJM78L05A | NJR | KQ | SOT89 | 78L 5.0V 0.1A regulator | |
| 8C | MMBZ5228B | Mot | C | SOT23 | 3.9V zener 0.225W | |
| 8C | MUN2213 | Mot | N | SOT23 | npn dtr 47k + 47k | |
| 8C | MUN5213 | Mot | N | SOT323 | npn dtr 47k + 47k | |
| 8D | MUN2214 | Mot | N | SOT23 | npn dtr 10k + 47k | |
| 8D | MUN5214 | Mot | N | SOT323 | MUN2214 | |
| 8E | NJM78L06A | NJR | KQ | SOT89 | 78L 6.0V 0.1A regulator | |
| 8E | FMMT-A92R | Zet | R | SOT23R | MPSA92 | |
| 8E | MMBZ5230B | Mot | C | SOT23 | 4.7V zener 0.225W | |
| 8E | MUN2215 | Mot | N | SOT23 | npn dtr R1 10k | |
| 8E | MUN5215 | Mot | N | SOT323 | npn dtr R1 10k | |
| 8F | NJM78L07A | NJR | KQ | SOT89 | 78L 7.0V 0.1A regulator | |
| 8F | MMBZ5231B | Mot | C | SOT23 | 5.1V zener 0.225W | |
| 8F | MUN2216 | Mot | N | SOT23 | npn dtr R1 4k7 | |
| 8F | MUN5216 | Mot | N | SOT323 | MUN2216 | |
| 8G | NJM78L08A | NJR | KQ | SOT89 | 78L 8.0V 0.1A regulator | |
| 8G | MMBZ5232B | Mot | C | SOT23 | 5.6V zener 0.225W | |
| 8G | MUN2230 | Mot | N | SOT23 | npn dtr 1k0+1k0 | |
| 8G | MUN5230 | Mot | N | SOT323 | npn dtr 1k0+1k0 | |
| 8H | NJM78L09A | NJR | KQ | SOT89 | 78L 9.0V 0.1A regulator | |
| 8H | MMBZ5233B | Mot | C | SOT23 | 6.0V zener 0.225W | |
| 8H | MUN2231 | Mot | N | SOT23 | npn dtr 2k2+2k2 | |
| 8H | MUN5231 | Mot | N | SOT323 | npn dtr 2k2+2k2 | |
| 8J | NJM78L10A | NJR | KQ | SOT89 | 78L 10V 0.1A regulator | |
| 8J | MMBZ5234B | Mot | C | SOT23 | 6.2V zener 0.225W | |
| 8J | MUN2232 | Mot | N | SOT23 | npn dtr 4k7+ 4k7 | |
| 8J | MUN5232 | Mot | N | SOT323 | npn dtr 4k7+ 4k7 | |
| 8K | NJM78L12A | NJR | KQ | SOT89 | 78L 12V 0.1A regulator | |
| 8K | MMBZ5235B | Mot | C | SOT23 | 6.8V zener 0.225W | |
| 8K | MUN2233 | Mot | N | SOT23 | npn dtr 4k7+ 47k | |
| 8K | MUN5233 | Mot | N | SOT323 | npn dtr 4k7+ 47k | |
| 8L | NJM78L15A | NJR | KQ | SOT89 | 78L 15V 0.1A regulator | |
| 8L | MMBZ5236B | Mot | C | SOT23 | 7.5V zener 0.225W | |
| 8L | MUN2234 | Mot | N | SOT23 | npn dtr 22k + 47k | |
| 8L | MUN5234 | Mot | N | SOT323 | npn dtr 22k + 47k | |
| 8M | NJM78L18A | NJR | KQ | SOT89 | 78L 18V 0.1A regulator | |
| 8M | MMBZ5237B | Mot | C | SOT23 | 8.2V zener 0.225W | |
| 8N | NJM78L20A | NJR | KQ | SOT89 | 78L 20V 0.1A regulator | |
| 8N | MMBZ5238B | Mot | C | SOT23 | 8.7V zener 0.225W | |
| 8P | NJM78L24A | NJR | KQ | SOT89 | 78L 24V 0.1A regulator | |
| 8P | MMBZ5239B | Mot | C | SOT23 | 9.1V zener 0.225W | |
| 8Q | MMBZ5240B | Mot | C | SOT23 | 10V zener 0.225W | |
| 8R | MMBZ5241B | Mot | C | SOT23 | 11V zener 0.225W | |
| 8S | MMBZ5242B | Mot | C | SOT23 | 12V zener 0.225W | |
| 8T | MMBZ5243B | Mot | C | SOT23 | 13V zener 0.225W | |
| 8U | MMBZ5244B | Mot | C | SOT23 | 14V zener 0.225W | |
| 8V | MMBZ5245B | Mot | C | SOT23 | 15V zener 0.225W | |
| 8V2 | PZM8.2NB | Phi | C | SOT23 | 8.2V 0.3W zener | |
| 8W | MMBZ5246B | Mot | C | SOT23 | 16V zener 0.225W | |
| 8X | MMBZ5247B | Mot | C | SOT23 | 17V zener 0.225W | |
| 8Y | MMBZ5248B | Mot | C | SOT23 | 18V zener 0.225W | |
| 8Y2 | BZV49-C8V2 | Phi | O | SOT89 | 8.2V 1W zener | |
| 8Z | NJM78L62A | NJR | KQ | SOT89 | 78L 6.2V 0.1A regulator | |
| 8Z | MMBZ5249B | Mot | C | SOT23 | 19V zener 0.225W | |
| Коды на ‘9’ | ||||||
| Code | Device | Manufacturer | Base | Package | Leaded Equivalent/Data | |
| 9 | BC849 | Mot | N | SOT23 | BC 549B | |
| 91 | ZV931V2 | Zet | I | SOD523 | 4-13.5pF hyperabrupt varicap | |
| 91 | DTA113TKA | Roh | N | SC59 | pnp dtr R11k0 50V 100mA | |
| 91A | FMMT591A | Zet | N | SOT23 | pnp 40V 1A 0.5W fT 150 MHz | |
| 92 | ZV932V2 | Zet | I | SOD523 | 5.5-17pF hyperabrupt varicap | |
| 92V | BFP92A | Tfk | W | — | npn RF 6GHz 16V 30mA | |
| 93 | ZV933V2 | Zet | I | SOD523 | 12-42pF hyperabrupt varicap | |
| 93 | DTA143TE | Roh | N | EMT3 | pnp dtr R1 4k7 50V 100mA | |
| 93 | DTA143TUA | Roh | N | SC70 | pnp dtr R1 4k7 50V 100mA | |
| 93 | DTA143TKA | Roh | N | SC59 | pnp dtr R1 4k7 50V 100mA | |
| 94 | DTA114TE | Roh | N | EMT3 | pnp dtr R1 10k 50V 100mA | |
| 94 | DTA114TUA | Roh | N | SC70 | pnp dtr R1 10k 50V 100mA | |
| 94 | DTA114TKA | Roh | N | SC59 | pnp dtr R1 10k 50V 100mA | |
| 95 | DTA124TE | Roh | N | EMT3 | pnp dtr R1 22k 50V 100mA | |
| 95 | DTA124TCA | Roh | N | SOT23 | pnp dtr R1 22k 50V 100mA | |
| 95 | DTA124TKA | Roh | N | SC59 | pnp dtr R1 22k 50V 100mA | |
| 96 | DTA144TE | Roh | N | EMT3 | pnp dtr R1 47k 50V 100mA | |
| 96 | DTA144TUA | Roh | N | SC70 | pnp dtr R1 47k 50V 100mA | |
| 96 | DTA144TKA | Roh | N | SC59 | pnp dtr R1 47k 50V 100mA | |
| 99 | DTA115TE | Roh | N | EMT3 | pnp dtr R1 100k 50V 100mA | |
| 99 | DTA115TUA | Roh | N | SC70 | pnp dtr R1 100k 50V 100mA | |
| 99 | DTA115TKA | Roh | N | SC59 | pnp dtr R1 100k 50V 100mA | |
| 911 | PZM9.1NB1 | Phi | C | SOT346 | 9.1V 0.3W zener | |
| 912 | PZM9.1NB2 | Phi | C | SOT346 | 9.1V 0.3W zener | |
| 913 | PZM9.1NB3 | Phi | C | SOT346 | 9.1V 0.3W zener | |
| 9A | FMMT2369AR | Zet | R | SOT23 | 2N2369A | |
| 9A | DTA125TUA | Roh | N | SC70 | pnp dtr R1 200k 50V 100mA | |
| 9A | DTA125TKA | Roh | N | SC59 | pnp dtr R1 200k 50V 100mA | |
| 9A | PLVA650A | Phi | C | SOT23 | 5.0V avalanche reg diode | |
| 9A1 | PZM9.1NB2A | Phi | A | SOT346 | dual ca 9.1V 0.3W zener | |
| 9B | NJM79L03UA | NJR | KQR | SOT89 | 79L reg 3.0V 0.1A | |
| 9B | PLVA653A | Phi | C | SOT23 | 5.3V avalanche reg diode | |
| 9C | NJM79L05UA | NJR | KQR | SOT89 | 79L reg 5.0V 0.1A | |
| 9C | PLVA656A | Phi | C | SOT23 | 5.6V avalanche reg diode | |
| 9D | PLVA659A | Phi | C | SOT23 | 5.9V avalanche reg diode | |
| 9E | NJM79L06UA | NJR | KQR | SOT89 | 79L reg 6.0V 0.1A | |
| 9E | PLVA662A | Phi | C | SOT23 | 6.2V avalanche reg diode | |
| 9F | PLVA665A | Phi | C | SOT23 | 6.5V avalanche reg diode | |
| 9G | NJM79L08UA | NJR | KQR | SOT89 | 79L reg 8.0V 0.1A | |
| 9G | PLVA668A | Phi | C | SOT23 | 6.8V avalanche reg diode | |
| 9H | NJM79L09UA | NJR | KQR | SOT89 | 79L reg 9.0V 0.1A | |
| 9J | PLVA2650A | Phi | A | SOT23 | dual ca 5.0V reg diode | |
| 9K | NJM79L12UA | NJR | KQR | SOT89 | 79L reg 12V 0.1A | |
| 9K | PLVA2653A | Phi | A | SOT23 | dual ca 5.3V reg diode | |
| 9L | NJM79L15UA | NJR | KQR | SOT89 | 79L reg 15V 0.1A | |
| 9L | PLVA2656A | Phi | A | SOT23 | >dual 5.60V reg diode | |
| 9M | NJM79L18UA | NJR | KQR | SOT89 | 79L reg 18V 0.1A | |
| 9M | PLVA2659A | Phi | A | SOT23 | dual ca 5.9V reg diode | |
| 9N | PLVA2662A | Phi | A | SOT23 | dual ca 6.2V reg diode | |
| 9O | PLVA2665A | Phi | A | SOT23 | dual ca 6.5V reg diode | |
| 9P | NJM79L24UA | NJR | KQR | SOT89 | 79L reg 24V 0.1A | |
| 9P | PLVA2668A | Phi | A | SOT23 | dual ca 6.8V reg diode | |
| 9P | BCX70HR | Zet | R | SOT23 | BCX70H | |
| 9R | FMMT2369R | Zet | R | SOT23 | 2N2369 | |
| 9V1 | PZM9.1NB | Phi | C | SOT346 | 9.1V 0.3W zener | |
| 9Y1 | BZV49-C9V1 | Phi | O | SOT89 | 9.1V 1W zener | |
Остальные коды смотрите в справочнике на другой странице.
Как паять транзисторы SMD
Транзисторы в SMD корпусе, очень удобны, особенно где каждый миллиметр платы важен. Представьте, как бы изменился мобильный телефон (плата которого полностью из SMD деталей), если бы там использовали обычные выводные DIP детали.
Выше фото SMD транзистора на фоне обычного, в TO 92.
Это фото различных СМД транзисторов, справа — обычный в TO92. Как правило, цоколёвка всех таких транзисторов одинакова — это тоже огромный плюс.
Название различных корпусов, DIP и SMD. Фото можно увеличить.
Как сделаны планарные транзисторы, вы можете увидеть ниже.
У планарных, как и у обычных транзисторов, есть множество видов, составные (Дарлингтон), полевые, биполярные и IGBT (биполярные транзисторы с изолированным затвором).
Обратите внимание, на платах и схемах транзисторы маркируются «Q» и «VT» (так должно быть, хотя некоторые производители брезгуют этим), зачем я это пишу? Часто в один и тот-же корпус, изготовитель может впихнуть всё, что ему хочется — от диода и до линейного стабилизатора напряжения (78хх), даже различных датчиков. Ещё существует внутренняя маркеровка завода, к примеру детали фирмы Epcos. На такие детали очень трудно найти даташит, а иногда его вовсе нет в интернете.
Работа с планарными полупроводниками
Паять такие транзисторы не трудно, особенно ускоряет и делает более легким, процесс пайки различных SMD деталек — микроскоп, пинцет (просто незаменимые вещи) различные флюсы и паяльные жиры с BGA-пастой. Сначала лудим контактные площадки нашего транзистора и платы (не перегрейте).
Затем позиционируем наш транзистор, я делаю это пинцетом.
Припаиваем любую из ножек. Отпускаем пинцет, и позиционируем нашу детальку как можно ровнее, для отличного вида, так сказать 🙂
Припаиваем оставшиеся «ножки» радиоэлемента.
И вот, наш транзистор крепко и хорошо припаян к плате. В следующих статьях, буду писать об этом всём подробнее (флюсы, пинцеты, пайка и т.д).
